HTC-LCR-4080Q LCR-Q Meter

HTC-LCR-4080Q LCR-Q Meter
HTC-LCR-4080Q LCR-Q Meter
HTC-LCR-4080Q LCR-Q Meter
HTC-LCR-4080Q LCR-Q Meter

HTC-LCR-4080Q LCR-Q Meter

Click To Zoom

HTC-LCR-4080Q LCR-Q Meter

HTC-LCR-4080Q LCR-Q Meter

(Based On 10 Reviews)

The HTC-LCR-4080Q is a digital LCR meter that measures inductance, capacitance, and resistance. It has a large LCD display, automatic identification of components, and high accuracy. It's suitable for a wide range of applications.

Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL PRODUCTS
Your source for authentic goods. No fakes, just the real deal.

100% ORIGINAL PRODUCTS

SECURE PAYMENTS
Risk-free Transactions

SECURE PAYMENTS

₹ 15,145

(GST inclusive price) i
  • Base Value: ₹ 12834.7
  • GST: (18) % ₹ 2310.3
  • Total Value ₹ 15145

₹17,590.00

( - 14% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

8920884830

Description

Key Features

  • Main display: 19,999 Count,
    Secondary display:1999 Count
  • Measurement frequency :
    100Hz/120Hz/1KHz/10KHz/100KHz
  • Measurement voltage : 0.6Vrms
  • Output impedance : 120Ω
  • LCR automatic identification/manual measurement
  • Open/short calibration
  • Power : 9V (6F22) X 1



What's in the box?

  • HTC-LCR-4080Q LCR-Q Meter
  • Soft Carrying Case
  • Test Leads
  • Holster
  • Manual.

Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0
Review Image

Product Specifications

INDUCTANCE GEAR (L) & Ls/Lp
 Display Range    Min. resolution    Accuracy : ±(a% of rdg +b dgts)
under 18 ~ 28ËšC
100Hz/120Hz    20.000mH1µH±(1.0%+5)
200.00mH0.01mH    Â±(0.5%+5)
2000.0mH0.01mH±(0.5%+5)
20.000H1mH±(0.5%+5)
200.0H0.01H±(1.0%+5)
2000.0H0.1H±(1.0%+5)
1KHz    2000.0µH0.1µH±(1.0%+5)
20.000mH1μH±(0.5%+5)
2000.00mH0.01mH±(0.5%+5)
2000.0mH0.1mH±(1.0%+5)
20.000H1mH±(1.0%+5)
2000.00H0.01H±(2.0%+5)
100KHz    200.000H0.01µH±(1.0%+5)
200.00µH0.01µH±(1.0%+5)
2000.0µH0.1µH±(0.5%+5)
20.00mH1µH±(0.5%+5)
100KHz    20.000µH0.001µH±(2.0%+5)
200.00μH0.01µH±(2.0%+5)
2000.0µH0.1µH±(2.0%+5)



RESISTANCE GEAR (R) & Rs/Rp
 Display Range    Min. resolution    Accuracy : ±(a% of rdg +b dgts)
under 18 ~ 28ËšC
100Hz/120Hz    200.00Ω0.01kΩ±(1.0%+5)
2.0000kΩ0.1Ω±(0.3%+5)
20.000kΩ1Ω    Â±(0.3%+5)
200.00kΩ0.01kΩ±(0.5%+5)
2.0000MΩ0.1kΩ±(1.0%+5)
20.000MΩ1kΩ±(2.0%+5)
1KHz    20.000Ω0.001Ω±(1.0%+5)
200.00Ω0.01Ω±(1.0%+5)
2.0000kΩ1Ω    Â±(0.3%+5)
20.000kΩ0.1kΩ±(0.3%+5)
200.00kΩ1kΩ±(0.5%+5)
2.0000MΩ0.01kΩ±(1.0%+5)
20.000MΩ0.1kΩ±(2.0%+5)
10KHz20.000Ω1kΩ±(1.0%+5)
200.00Ω0.001Ω±(1.0%+5)
2.0000kΩ0.01Ω±(0.3%+5)
20.000kΩ0.1Ω±(0.5%+5)
200.00kΩ1Ω±(1.0%+5)
2.0000MΩ0.01kΩ±(2.0%+5)
100KHz20.000Ω0.1kΩ±(2.0%+5)
200.00Ω0.001Ω±(2.0%+5)
2.0000kΩ0.01Ω±(1.0%+5)
20.000kΩ0.1Ω±(2.0%+5)
200.00Ω0.01Ω±(1.0%+5)



CAPACITANCE CAP GEAR (C) & Cs/Cp
 Display Range    Min. resolution    Accuracy : ±(a% of rdg +b dgts)
under 18 ~ 28ËšC
100Hz/120Hz    20.000nF1pF±(2.0%+5)
200.00nF0.01nF±(0.5%+5)
2000.0nF0.1nF±(0.5%+5)
20.000µF1nF±(0.5%+5)
200.00μF0.01µF±(1.0%+5)
2000.0µF0.1µF±(2.0%+5)
20.00mF0.1mF    Â±(2.0%+5)
1KHz    2000.0pF0.1pF±(1.0%+5)
20.000nF1pF±(1.0%+5)
200.00nF0.01nF±(0.5%+5)
200.00nF0.1nF±(0.5%+5)
20.000μF1nF±(0.5%+5)
200.00µF0.01µF±(1.0%+5)
2000.0µF0.1µF±(1.0%+5)
10KHz    2000.0pF0.1pF±(1.0%+5)
20.000nF1pF±(1.0%+5)
200.00nF0.01nF±(1.5%+5)
2000.0nF0.1nF±(2.0%+5)
100KHz    2000.0pF0.1pF±(2.0%+5)
20.000nF1pF±(2.0%+5)
200.00nF0.01nF±(5.0%+5)
