Metravi DDS-1025 DDS Function Generator

Click To Zoom

Metravi DDS-1025 DDS Function Generator

Metravi DDS-1025 DDS Function Generator

(Based On 10 Reviews)

Metravi DDS-1025 Series function/arbitrary Waveform Generator adopts the DDS technique into its design and is capable of generating accurate and stable waveforms with a resolution down to 1mHz. It is a type of function / arbitrary waveform generator with a high performance-price ratio and multiple functions packed just into one instrument. The output is accurate, stable, and pure with minimum distortion. The square wave offered is high in frequency and has very fast rising and falling edges.

Request Callback

Order In Bulk

Generate Quote

₹ 58,482.00

(GST inclusive price) i
  • Base Value: ₹ 49561
  • GST: (18) % ₹ 8921
  • Total Value ₹ 58482

₹58,482.00

( - 0% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

8920884830

Description

Key Features

  • 60 MHz ( or 25 MHz) sinewave out, down to 1μHz resolution for full frequency range.
  • 25 MHz (or 5 MHz) pulse waveform with adjustable rise & fall time and duty cycle.
  •  250MSa/s (or 125Msa/s) sample rate and 14-bit vertical resolution.
  •  6-digit precision meter that is compatible with TTL level signal
  •  Standard dual channels with independent output mode
  •  1M (or 8K) arbitrary waveform memory and 48 waveforms non-volatile storage.
  •  Multiple modulation types: AM, FM, PM, ASK, FSK, PSK, PWM.
  •  Powerful software available to use on PC.
  •  4.3-inch high-resolution TFT color display
  •  Standard Interfaces: USB Host, USB Device, optional Lan.
  • Usual channels can be applied at the same time or independently: internal/external
  • modulation, internal/external, Manual trigger.
  •  Support frequency sweep and burst output
  •  Ease-of-use multipurpose knob and numeric keypad



What's in the box?

  •  DDS Function Generator

Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0

Product Specifications

Technical Specification
TypeDDS - 1010
ChannelSingle Channel
Max. Frequency10MHz
Sample Rate 125MSa/s
WaveformSine Wave, Square Wave, Triangle Wave, Pulse Wave, Ramp Wave,
Noise, DC, Arbitrary Waveform
Working ModeOutput Stobe, Duration, Modulation, Scanning
Modulation TypeAM, FM, PM, ASK, FSK, PSK, PWM



Features of Waveform
Sine Wave
Frequency Range1μHz~10MHz
Resolution1μHz
Accuracy±50ppm in 90 days, ±100ppm in one year (18°C~28°C)
Harmonic Distortion
(Typical Value)		Test Condition: Output power 0dBm
-55dBc
-50dBc
-40dBc
Total Harmonic Distortion
(Typical Value)		DC~20kHz, 1Vpp < 0.2%



Square Wave
Frequency Range1μHz ~ 5MHz
Resolution1μHz
Lead/Tail Time< 24ns (typical value, 1kHz, 1Vpp)
Overshoot (Typical Value)< 2%
Duty Cycle0.01% ~ 99.99%
Min. Pulse≥80ns
Jittering(Typical Value)1ns+ 100ppm of period



Ramp Wave
Frequency Range1μHz~400kHz
Resolution1μHz
Nonlinear Degree1%±2 mV (typical value, 1kHz, 1Vpp, symmetry 50%)
Symmetry0.0% to 100.0%
Min. Edge Time≥400ns



Pulse Wave
Frequency Range1μHz ~ 5MHz
Resolution1μHz
Pulse Eidth≥80ns
Lead/Tail Time24ns (typical value, 1kHz, 1Vpp)
Overshoot (Typical Value)2%
Jittering (Typical Value)1ns+ 100ppm of period



DC Offset
Range (Peak Value AC+DC)±5V (50Ω)
±10V (High Resistance)
Offset Precision±(1% of offset setting+0.5% of ampltide +2mV)



Features of Arbitrary Waveform
Frequency Range1μHz ~ 2MHz
Resolution1μHz
Waveform Length2048 points
Vertical Resolution14bits (including symbols)
Sample Rate125MSa/s
Non-volatile Memory16 types of waveform



Output Features
Amplitude Range1mVpp ~ 10Vpp
50Ω
2mVpp ~ 20Vpp (high resistance)
<1% of amplitude setting value ±2 mV
Accuracy (Sine wave of 1kHz)
Amplitude Flatness
(relative to sine wave of 1kHz,
1Vpp/50Ω)		<100kHz 0.1dB
100kHz ~ 10MHz 0.2dB



Waveform Output
ImpedanceTypical value of 50Ω
InsulationTo earth wire, max.42Vpk
ProtectionShort-circuit Protection



Modulation Type
AM Modulation
Carrier WaveSine Wave, Square Wave, Ramp Wave, Arbitrary Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency2mHz ~ 50kHz
Modulation Depth0% ~ 120%



FM Modulation
Carrier WaveSine Wave, Square Wave, Ramp Wave, Arbitrary Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency2mHz ~ 50kHz
Frequency Offset1μHz ~ 5MHz 1μHz ~ 2.5MHz



PM Modulation
Carrier WaveSine Wave, Square Wave, Ramp Wave, Arbitrary Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency2mHz ~ 50kHz
Phase Offset0° ~ 360°



ASK Modulation
Carrier WaveSine Wave, Square Wave, Ramp Wave, Arbitrary Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency2mHz ~ 50kHz



FSK Modulation
Carrier WaveSine Wave, Square Wave, Ramp Wave, Arbitrary Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency



PSK Modulation
Carrier WaveSine Wave, Square Wave, Ramp Wave, Arbitrary Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency2mHz ~ 50kHz



PWM Modulation
Carrier WavePulse Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency2mHz ~ 50kHz
Arbitrary Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency2mHz ~ 50kHz
Phase Offset0° ~ 360°



ASK Modulation
Carrier WaveSine Wave, Square Wave, Ramp Wave, Arbitrary Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency2mHz ~ 50kHz



FSK Modulation
Carrier WaveSine Wave, Square Wave, Ramp Wave, Arbitrary Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency



PSK Modulation
Carrier WaveSine Wave, Square Wave, Ramp Wave, Arbitrary Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency2mHz ~ 50kHz



PWM Modulation
Carrier WavePulse Wave
SourceInternal / External
Modulation ShapeSine Wave, Square Wave, Ramp Wave, Noise, Arbitrary Wave
Modulation Frequency2mHz ~ 50kHz



Environment
Temperature RangeOperation: 10°C ~ +40°C
Non operation: -20°C ~ +60°C
Cooling MethodFan cooling
Humidity Range+35°C below: ≤ 90% relative humidity
+35°C ~ +40°C: ≤ 60% relative humidity
AltitudeOperation: below 2000 meters
Non Operation: below 15000 meters



Machine
Size (Reference Data)165mm×320mm×110mm
Net Weight3.10kg
Gross Weight4.10kg
