Metravi 45-TRMS Bench Type Multimeter
Click To Zoom
Metravi 45-TRMS Bench Type Multimeter
Metravi 45-TRMS Bench Type Multimeter
This instrument is a high-performance, 4½ digits bench multimeter for measuring DC and AC Voltage, DC and AC Current, Resistance, Capacitance, eHz, hFE, Diodes and Continuity. The max. voltage measuring can up to 1000V DC or AC peak value, resolution can be 10µV and current measuring can up to 20A, it also has the function of polarity auto-change, back-lit display and directly reading. For AC measuring it is performed by high accuracy RMS, has the feature of width measuring, and to get accurate RMS for AC flow of any wave shape.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
1 YEAR WARRANTY
AUTHORIZED DISTRIBUTOR
B2B INVOICES
₹ 9,950
(GST inclusive price) i-
Base Value: ₹ 8432.2
-
GST: (18) % ₹ 1517.8
-
Total Value ₹ 9950
₹14,216.00
( - 30% OFF )
Description
Key Features
- Power supply: 220V/ 110V AC
- Manual range
- 41/2-digit large LCD display with backlight(displaying range: 75 x 40 mm), max.reading: 19999
- Voltage measurement up to 1000VDC and 750V AC
- DC, AC up to 20A
- ACV frequency response: 50kHz
- Frequency, Resistance, Capacitance measurement, Triode, Diode check and Continuity Test
- Overload protection: 250V rms
- Operation environment: 0°C-40°C,<75%R.H
- Dimension: 260mm x 220mm x 82mm
- Weight: approx. 1 kg
What's in the box?
|
Rating & Reviews
Rating
| Technical Specification | ||
| DC VOLTAGE | ||
| Range | Accuracy | Resolution |
| 200mV | ± (0.05% RDG +3) | 10uV |
| 2V | 100uV | |
| 20V | 1mV | |
| 200V | 10mV | |
| 1000V | ± (0.1% RDG +5) | 100mV |
| AC VOLTAGE | |||
| Range | Input Frequency | Accuracy | Resolution |
| 200mV | 50Hz-50kHz | ± (0.8% RDG +80) | 10uV |
| 2V | 100uV | ||
| 20V | 50Hz-20kHz | 1mV | |
| 200V | 50Hz-5kHz | 10mV | |
| 750V | 50Hz-400kHz | ± (1.0% RDG+50) | 100mV |
| DC CURRENT | ||
| Range | Accuracy | Resolution |
| 20mA | ±(0.35% RDG+10) | 1μΑ |
| 200mA | 10μΑ | |
| 2A | ± (0.8% RDG+10) | 100μΑ |
| 20A | 1mA | |
| AC CURRENT | |||
| Range | Input Frequency | Accuracy | Resolution |
| 200mA | 50Hz-5kHz | ±(0.8% RDG+80) | 10μΑ |
| 2A | 50Hz-400Hz | ±(1.0% RDG+50) | 100μΑ |
| 20A | 1mA | ||
| RESISTANCE | ||
| Range | Accuracy | Resolution |
| 200 Ω | ± (0.1% * RDG + 20) | 0.01 Ω |
| 2kΩ | ± (0.1% * RDG + 5) | 0.1 Ω |
| 20k Ω | 1Ω | |
| 200k Ω | 10 Ω | |
| 2Μ Ω | 100 Ω | |
| 20Μ Ω | ± (0.4% * RDG + 5) | 1k Ω |
| CAPACITANCE | ||
| Range | Accuracy | Resolution |
| 20nF | ± (3.5% + 20) | 1pF |
| 2uF | 100pF | |
| 200uF | ± (5% + 30) | 10nF |
| FREQUENCY | ||
| Range | Accuracy | Resolution |
| 20kHz | ± (1% + 20) | 0.1Hz |
| 200kHz | 1Hz | |
