Metravi PM-29 Process Meter

Metravi PM-29 Process Meter
Metravi PM-29 Process Meter

Metravi PM-29 Process Meter

Click To Zoom

Metravi PM-29 Process Meter

Metravi PM-29 Process Meter

(Based On 10 Reviews)

4 & 5 digits Digital Multimeter and DC mV / Voltage / Frequency / Resistance / mA Calibrator and also provides output for all types of Thermocouples

Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL PRODUCTS
Your source for authentic goods. No fakes, just the real deal.

100% ORIGINAL PRODUCTS

SECURE PAYMENTS
Risk-free Transactions

SECURE PAYMENTS

1 YEAR WARRANTY
1 Year Warranty Against Any Manufacturing Defects.

1 YEAR WARRANTY

AUTHORIZED DISTRIBUTOR
Get genuine products and full manufacturer support. We are an authorized distributor for Fluke, Meco, Metravi, Mextech, Lutron & SEW.

AUTHORIZED DISTRIBUTOR

B2B INVOICES
Enter your GSTIN at the time of checkout for claiming GST input.

B2B INVOICES

₹ 48,150

(GST inclusive price) i
  • Base Value: ₹ 40805.1
  • GST: (18) % ₹ 7344.9
  • Total Value ₹ 48150

₹68,850.00

( - 30% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

8920884830

Description

Key Features

  • Measurement functions: AC Voltage, DC Voltage, Resistance, Capacitance, DC Current, AC Current, Diode Test, Frequency, Thermocouple Temperature and Thermal Resistance
  • Output functions: DC Voltage, Resistance, Frequency, Thermocouple Temperature, Thermal Resistance and DC Current (constant output, manual stepping and SIMULATE).
  • Loop inspection: supply power to 24V circuits and meanwhile measure current.
  • Built-in VFC Low Pass Filter can accurately measure distorted voltage and variable frequency voltage.
  • Data display and retention.
  • Measurement of relative values.



What's in the box?

  • Metravi PM-29 Process Meter

Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0
Review Image

Product Specifications

GENREAL

Overload protectionV~COM terminal：AC1000V/10 seconds mAV terminal：630mA/250V quick-acting fuse
Regulatory complianceIEC61010-1 (CATIV 600V, CATIII 1000V, Pollution Level II
Electromagnetic compatibilityConsistent with Group 1 and Class B of IEC61326-1
Surge protection8kV(As per IEC61010.1-2001)
Authentication markCE
Quality standardIt is developed, designed and produced according to ISO 9001.
Display4 digit display for measurement, 5 digit display for output
Display refreshingFast (F): 20times/second; slow (S): 5 times/second
Temperature and humidity range for work0～40 ºC, relative humidity ≤85% (without moisture condensation)
Temperature and humidity range for storage-20 ºC～60 ºC, relative humidity below 90% (without moisture condensation)
Temperature and humidity range for guaranteed precision23±5ºC, relative humidity below 75% (without moisture condensation)
Temperature factor0.1× basic precision / °C (temperature range: <18°C or >28°C)
Application environmentIndoors, outdoors (non-watertight), altitude of 0～2000m
Indication of outrangeOL
On-off / open-circuit testBuzzer beeps indicate the resistance reading is lower than the threshold, or an open circuit
Battery typeThree 1.5V (LR6) alkaline batteries
Service life of batteries

When using alkaline batteries

Measuring any parameter: about 100mVA

Loop detection function: about 200mVA

DC current output (SIMULATE): about 200mVA

DC current output (SOURCE) 20mA (1000Ω load): about 1000mVA"

Battery lowit is indicated with a battery mark.
Automatic shutdownThe meter is automatically shut down after about 5 minutes of no operation. The time can be adjusted.
Warm-up time10 minutes
Close the meter enclosure calibrationNo need for internal adjustment
Battery coverFor battery replacement, without influencing meter calibration
Size185（L）×90（W）×54（D）mm
WeightAbout 500g

TECHNICAL

Function Range Measuring scopeResolution
 		Precision
DC voltage DCV60mV -60.00mV~60.00mV 0.01mV 0.2%+4
600mV -600.0mV~600.0mV 0.1mV0.2%+4
6V -6.000V~6.000V 0.001V 0.2%+4
600V -600.0V~600.0V 0.1V 0.2%+4
1000V -1000V~1000V 1V 0.2%+4
AC voltage ACV6V
 		0 ~ 6.000V 0.001V 5\%+40(> 400Hz ) 7.5\%+40(< 400Hz )
60v0~60.00V 0.01V 0.5%+4
600V0~600.0V 0.1V 0.5%+4
VFC600V 0~600.0V 0.1V 4%+10
OHM600Ω 0~600.00 0.1Ω0.2%+4
6ΚΩ 0~6.000ΚΩ 0.001ΚΩ 0.2%+4
60ΚΩ 0~60.00ΚΩ 0.01ΚΩ 0.2%+4
600ΚΩ 0~600.0ΚΩ 0.1ΚΩ 0.5%+4
6ΜΩ 0~6.000ΜΩ 0.001ΜΩ 1%+4
60ΜΩ 0~60.00ΜΩ 0.01ΜΩ 2%+4
DC current DCI60mA -60.00mA~60.00mA 0.01mA 0.2%+4
600mA -600.0mA~600.0mA 0.1mA 0.2%+4
AC current ACI60mA 0.00mA~60.00mA 0.01mA 0.5%+10
600mA 0.0mA~600.0mA 0.1mA 0.5%+10
Frequency FREQ10Hz 0~9.9999Hz 0.0001Hz 0.02%+4
100Hz 0~99.999Hz 0.001Hz 0.02%+4
1000Hz 0~999.99Hz 0.01Hz 0.02%+4
10kHz 0~5.0000kHz 0.0001kHz 0.02%+4
DUTY 10%~90% 0.10% 1%
Diode2V 0.0001V 1% + 10
600ΚΩ  0.1Ω<= 50OmegaΩBB
Thermocouple TCR0~1760°C1°C

0.5% +3°C(<=100) °C

0.5% +2°C(>100)°C

S0~1760°C
B600~1800°C
K -200~1350°C0.5%+2°C(≤-100) "C
0.5%+1°C(>-100) °C
E-200~700°C
J-200~950°C
T-200~400°C
N-200~1300°C
Thermal resistance RTD Cu50 -50~150°C 1°C0.5%+3°C
Pt100 -200~850°C
Pt1000-200~800°C
