Metravi CTG-02 Coating Thickness Gauge
Click To Zoom
Metravi CTG-02 Coating Thickness Gauge
Metravi CTG-02 Coating Thickness Gauge
Measures Coating thickness on both ferrous and non-ferrous materials. Also comes with an external probe.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL Products
SECURE Payments
₹ 22,517.00
(GST inclusive price) i₹30,308.00
( - 26% OFF )
Description
What's in the box?
|
Rating & Reviews
Rating
| General Specification | ||
| Sensor probe | F | N |
| Working principle | Magnetic Induction | Eddy Current principle |
| Measuring range | 0~2000um 0~78.7mils | 0~2000um 0~78.7mils |
| Guaranteed Tolerance (of readings) | 0~1000 um (±2%+2um) 1000um~2000 um (±3.5%) 0~39.3 mils ( ± 3% + 0.08 mils) 39.3~78.7mils (±3.5%) | 0~1000 um (±2%+2um) 1000um~2000 um (±3.5%) 0~39.3 mils ( ± 3% + 0.08 mils) 39.3~78.7mils (±3.5%) |
| Precision | 0~100um (0.1um) 100um~1000um (1um) 1000um~ 2000um(0.01mm) 0~ 10mils (0.01mils) 10~78.7mils(0.01mils) | 0~100um (0.1um) 100um~1000um (1um) 1000um~ 2000um(0.01mm) 0~ 10mils (0.01mils) 10~78.7mils(0.01mils) |
| Minimum curvature radius | 1.5mm | 3mm |
| Diameter of Minimum area | 7mm | 5mm |
| Minimum measurable thickness | 0.5mm | 0.3mm |
| Working temperature | 0° C~40° C(32° F ~ 104° F ) | |
| Working relative humidity | 20% ∼90% | |
