Kusam Meco KM 1790 CLAMP GROUND RESISTANCE TESTER
Click To Zoom
Kusam Meco KM 1790 CLAMP GROUND RESISTANCE TESTER
Kusam Meco KM 1790 CLAMP GROUND RESISTANCE TESTER
Kusam Meco KM 1790 is a handheld digital vibration meter used to measure vibration velocity, acceleration, and displacement. It’s ideal for monitoring machinery health, ensuring predictive maintenance, and identifying mechanical faults in industrial equipment efficiently.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
₹ 37,100
(GST inclusive price) i-
Base Value: ₹ 31440.7
-
GST: (18) % ₹ 5659.3
-
Total Value ₹ 37100
₹61,085.00
( - 23% OFF )
Description
Key Features
- New black screen design, luxury
- Ω+A same screen display
- Quick self-test function without waiting
- Using fast filtering technology, strong anti-interference ability
- New design, long life clamp head
- 300 sets of storage
- Resistance Range: 0~1200Ω
- Resistance resolution: 0.001Ω
- Current Range: 0~20A
- Current resolution: 0.01mA
- Multifunctional Type
What's in the box?
|
Rating & Reviews
Rating
| Function | Ground resistant test, Loop resistance test, leakage current test | ||
| Range | Ground resistant: 0.01Ω-1200Ω | Resolution: 0.001Ω | Accuracy: ±1%±0.01Ω |
| Current : 0.00mA-20.0A | Resolution: 0.01mA | Accuracy: ±2%±1mA | |
| Ambient temperature and humidiy | 23℃±5℃, below 75%rh | ||
| Power Supply | 4 section 5 Alkaline Dry Battery | ||
| Measurement Method | Mutual induction | ||
| Clamp Diameter | 55mmx32mm | ||
| Ω+A Synchronized display | Ω+A same screen display | ||
| Display Mode | 4-digit LCD display, black screen design | ||
| LCD Dimension | 46mm×29mm | ||
| Meter Dimension | W/T/H: 85mm×58mmx285mm | ||
| Sampling Speed | About 2 times/second | ||
| Data Storage | 300 Groups, the symbol “MEM” gives indication, “FULL” mark will flash to indicate the memory has been full | ||
| Data Review | "MR" symbol indication when reviewing data | ||
| Overflow Display | Exceed measurement range overflow function: “OL ” symbol display | ||
| Interference Test | Automatic identify interference signal, "NOISE" symbol indication when the interference current is large | ||
| Alarm Function | Alarm when the measured value exceeds the alarm setting value | ||
| Battery Voltage | Real-time display of battery power, reminding timely charging when battery voltage is low | ||
| Automatic shut-down | "APO" instruction, automatic shutdown after 5 minutes boot | ||
| Power Consumption | 50MA Max | ||
| Weight | Instrument: 1180g (with battery) | ||
| Working Temperature and Humidity | -10°C~40C; below 80% rh | ||
| Storage Temperature and Humidity | -20°C~60C; below 70% rh | ||
| Insulation Resistance | 20Ω or more (500V between circuit and outside) | ||
| Pressure Resistance | AC 3700V/rms(between circuit and outside) | ||
| External magnetic field | <40A/m | ||
| External electric field | <1V/m | ||
| Suitable for Safety Regulations | IEC61010-1(CAT III 300V, CAT IV 150V, Pollution Degree 2); IEC61010-031; IEC61557-1 (grounding resistance) | ||
