Lutron MO-2013 HIGH PRECISION MILLIOHM METER

Lutron MO-2013 HIGH PRECISION MILLIOHM METER
Lutron MO-2013 HIGH PRECISION MILLIOHM METER
Lutron MO-2013 HIGH PRECISION MILLIOHM METER

Click To Zoom

Lutron MO-2013 HIGH PRECISION MILLIOHM METER

Lutron MO-2013 HIGH PRECISION MILLIOHM METER

(Based On 10 Reviews)

The MO-2013 High Precision Milliohm Meter offers accurate and reliable measurements for low resistance components, making it an essential tool for various applications in industrial environments and quality control.

Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL Products
100% ORIGINAL Products Details

100% ORIGINAL Products

₹ 24,214.00

(GST inclusive price) i
  • Base Value: ₹ 20520.3
  • GST: (18) % ₹ 3693.7
  • Total Value ₹ 24214

₹24,214.00

( - 0% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

8920884830

Description

Key features



  •  4-Terminal Measurement: Ensures accurate measurement of very low resistance by eliminating lead resistance errors.
  •  Wide Measuring Range: Measures resistance from 0.001 milliohms to 20 kilohms across seven ranges.
  •  High/Good/Low Set-Function: Provides input quality control with an audible buzzer for good status.
  •  RS232/USB Interface: Allows for data transfer to a PC for further analysis and reporting.
  •  Built-In Calculate Function: Measures cable or wire length precisely.






What's in the box?

  • Standard Power Cord (1 PC)
  •  4-wire with 2 Kelvin Clips (1 Pair)
  •  Instruction Manual (1 PC)

















Optional Accessories:

RS232 Cable (UPCB-02)

 USB Cable (USB-01)

 Data Acquisition Software (SW-U801-WIN)

Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0
Review Image

Product Specifications

Technical Specifications:





 Measurement Ranges:

  •    20 mΩ, 200 mΩ, 2 Ω, 20 Ω, 200 Ω, 2 kΩ, 20 kΩ

 Resolution:

  •    0.001 mΩ (20 mΩ range)
  •    0.01 mΩ (200 mΩ range)
  •    0.0001 Ω (2 Ω range)
  •    0.001 Ω (20 Ω range)
  •    0.01 Ω (200 Ω range)
  •    0.0001 kΩ (2 kΩ range)
  •    0.001 kΩ (20 kΩ range)

 Test Current:

  •    1 A (20 mΩ, 200 mΩ ranges)
  •    100 mA (2 Ω range)
  •    10 mA (20 Ω range)
  •    1 mA (200 Ω range)
  •    100 μA (2 kΩ range)
  •    10 μA (20 kΩ range)

 Accuracy:

  •    ± (0.2% + 12d) for 20 mΩ range
  •    ± (0.2% + 4d) for other ranges

 Display:

  •    26.7 mm large size and back-light LCD display for easy readout


 Data Output:

  •    RS232/USB PC serial interface




  General Specifications:


   Operating Temperature:

  • 0 to 50℃ (32 to 122℉)

   Operating Humidity:

  • Less than 80% RH

   Power Supply:

  • AC 110V ± 15%, 50/60 Hz or AC 230V ± 15%, 50/60 Hz

   Power Consumption:

  •      AC 110V: Approx. 33 mA
  •      AC 230V: Approx. 15 mA

   Dimensions:

  • 280 x 210 x 90 mm (11.0 x 8.3 x 3.5 inches)

    Weight:

  • Approx. 2.04 kg (4.49 lbs)
