Lutron AM-4207SD Anemometer

Lutron AM-4207SD Anemometer
Lutron AM-4207SD Anemometer
Lutron AM-4207SD Anemometer
Lutron AM-4207SD Anemometer

Click To Zoom

Lutron AM-4207SD Anemometer

Lutron AM-4207SD Anemometer

(Based On 10 Reviews)

The LUTRON AM-4207SD is an anemometer with external probe, that can measure gas flow rate in range 0,4 - 30,0 m/s and temperature in range -100 - 1300 °C by K-type thermocouple. This device is capable of storing measurements onto SD card and can communicate via RS232 or USB.

Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL Products
100% ORIGINAL Products Details

100% ORIGINAL Products

SECURE Payments
SECURE Payments Details

SECURE Payments

₹ 14,600.00

(GST inclusive price) i
  • Base Value: ₹ 12372.9
  • GST: (18) % ₹ 2227.1
  • Total Value ₹ 14600

₹20,600.00

( - 29% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

8920884830

Description

Key Features

  • Air velocity : m/S, Ft/min, Km/h, Knots, Mile/h,
  • Air temperature ( , )
  • Low-friction ball vane wheels make sure high accuracy in high & low velocities.
  • Type K, Type J thermocouple thermometer
  • Air Temp. used thermistor sensor, fast response time.
  • Real time SD memory card Datalogger, it Built-in Clock and Calendar, real time data recorder , sampling time set from 1 second to 3600 seconds
  • Manual datalogger is available ( set the sampling time to 0 ), during execute the manual datalogger function, it can set the different position ( location ) No. ( position 1 to position 99 ).
  • Innovation and easy operation, computer is not need to setup extra software, after execute datalogger, just take away the SD card from the meter and plug in the SD card into the computer, it can down load the all the measured value with the time information ( year/month/date/ hour/minute/second ) to the Excel directly, then user can make the further data or graphic analysis by themselves.
  • SD card capacity : 1 GB to 16 GB.
  • LCD with green light backlight, easy reading.
  • Can default auto power off or manual power off.
  • Data hold, record max. and min. reading.
  • Microcomputer circuit, high accuracy
  • Power by UM3/AA ( 1.5 V ) x 6 batteries or DC 9V adapter
  • RS232/USB PC COMPUTER interface.
  • Separate probe, easy for operation of different measurement environment.
  • Wide applications: use this anemometer to check air conditioning & heating systems, measure air velocities wind temperature...etc.



What's in The Box ?

  • Instruction manual
  • Anemometer probe
  • Hard carrying case











Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0
Review Image

Product Specifications

GENERAL SPECIFICATIONS
CircuitCustom one-chip of microprocessor LSI circuit
DisplayLCD size : 52 mm x 38 mm LCD with green backlight ( ON/OFF ).
Measurement Unit

Air velocity: m/S (meters per second) Km/h ( kilometers per hour )Ft/min ( FPM, feet per minute ) Knots ( nautical miles per hour )Mile/h ( mph, miles per hour )

Air temperature: ℃ ℉,

Type K/ Type J thermometer: ℃ ℉,

Datalogger Sampling Time Setting range

Auto: 1 second to 3600 seconds  @ Sampling time can set to 1 second but memory data may loss

Manua: Push the data logger button once will save data one time. @ Set the sampling time to 0 second.@ Manual mode, can also select the 1 to 99 position ( Location ) no

Memory CardSD memory card. 1 GB to 16 GB
Advanced setting* Set clock time ( Year/Month/Date Hour/Minute/ Second ) Decimal point of SD card setting,  Auto power OFF management, Set beep Sound ON/OFF ,Set thermometer type to Type K or Type J, Set temperature unit to or ℃ ℉, Set sampling time, SD memory card Format
Data HoldFreeze the display reading.
Temperature CompensationAutomatic temp. compensation for the Anemometer function and the type K/J thermometer.
Memory RecallMaximum & Minimum value.
Sampling Time of DisplayApprox. 1 second
Data OutputRS 232/USB PC computer interface Connect the optional RS232 cable UPCB-02 will get the RS232 plug., Connect the optional USB cable USB-01 will get the USB plug
Operating Temperature0 to 50 °C.
Operating HumidityLess than 85% R.H.
Power SupplyAlkaline or heavy duty DC 1.5 V battery (UM3, AA) x 6 PCs, or equivalent. DC 9V adapter input. (AC/DC power adapter is optional)
Power CurrentNormal operation (w/o SD card save data and LCD Backlight is OFF): Approx. DC 15 mA., When SD card save the data and LCD Backlight is OFF): Approx. DC 36 mA.
Weight515 g/1.13 LB.
DimensionMain instrument: 203 x 76 x 38 mm
Anemometer sensor head: Round, 72 mm Dia.



























































Electrical Specification
Air Velocity
MeasurementRangeResolutionAccuracy
m/S0.4 - 30.0 m/s0.1 m/S± ( 2%+0.2 m/S)
Km/h1.4 - 126.0 Km/h0.1 Km/h± ( 2%+0.8 Km/h)
mph ( Mile/h )0.9 - 78.3 mph0.1 mph± ( 2%+0.4 mph)
Knots0.8 - 68.0 knots0.1 Knots± ( 2%+0.4 Knots)
FPM ( Ft/min )79 - 6890 FPM1 FPM± ( 2%+40 FPM)



















Air Temperature
Measuring Range0 ℃ to 50 ℃ /32℉ to 122  ℉
Resolution0.1 /0.1 ℃ ℉
Accuracy± 0.8 /1.5 ℃ ℉





Type K/J thermometer
Sensor TypeResolutionRangeAccuracy
Type K

0.1 ℃

0.1 ℉

-50.0 to 1300.0 ℃

-50.1 to -100.0 ℃

-58.0 to 2372.0 ℉

-58.1 to -148.0 ℉

± ( 0.4 % + 0.5 )

± ( 0.4 % + 1 )

± ( 0.4 % + 1 )

± ( 0.4 % + 1.8 )

Type J

0.1 ℃

0.1 ℉

-50.0 to 1200.0 ℃

-50.1 to -100.0 ℃

-58.0 to 2192.0 ℉

-58.1 to -148.0 ℉

± ( 0.4 % + 0.5 )

± ( 0.4 % + 1 )

± ( 0.4 % + 1 )

± ( 0.4 % + 1.8 )
