Metravi AVM-05 Thermo Anemometer with CMM and CFM
Click To Zoom
Metravi AVM-05 Thermo Anemometer with CMM and CFM
Metravi AVM-05 Thermo Anemometer with CMM and CFM
Digital Thermo-Anemometer with facility to measure wind flow (CFM / CMM).
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
 bl.png)
1 YEAR WARRANTY
AUTHORIZED DISTRIBUTOR
B2B INVOICES
₹ 7,898.00
(GST inclusive price) i₹10,631.00
( - 26% OFF )
Description
What's in the box?
|
Rating & Reviews
Rating
| General Specification | |
| Circuit | Custom LSI microprocessor circuit |
| Measurement units | Air Velocity: m / s ft / min km/h,MPH, knots; Air Flow: CFM (ft 3 / min) CMM (m3 / min) Temp: °C °F |
| Display | Display Type: LCD Display Size: 42×54mm |
| Data hold | Freezes displayed reading |
| Sensors | Air velocity sensor: conventional angled vane arms with low-friction ball bearing. |
| Temperature sensor | NTC-type thermo resistance |
| Sampling rate | 1 reading per second approx. |
| MAX/MIN Memory | Record and view Maximum and Minimum readings |
| Automatic Power off | Auto shut off after 20 minutes to save battery |
| Operating Temperature | 32 °F to 122° F ( 0 ° C to 50° C ) |
| Operating Humidity | MAX.80%RH |
| Power Supply | 9V battery Battery Life: 100 hours approx. |
| Power current | Approx. 2.5mA DC |
| Weight | 1.6 lbs(0.7kg) including battery & probe |
| Dimensions | Main instrument: 178 ×74×33mm Sensor Head: 70mm Diameter |
| Technical Specification | |||
| Range of Air Velocity | |||
| Air Velocity | Range | Resolution | Accuracy |
| m/s(meter per second) | 0.40-30.00 | 0.01 | ±3% ±0.20 m/s |
| ft/min(feet per minute) | 80-5900 | 1 | ±3% ±40 ft/min |
| Km/h(kilometers per hour) | 1.4-108.0 | 0.1 | ±3% ±0.8 km/h |
| MPH(miles per hour) | 0.9-67.0 | 0.1 | ±3% ±0.4 MPH |
| Knots(nautical miles per hour) | 0.8-58.0 | 0.1 | ±3% ±0.4 knots |
| CFM and CMM mode | |||
| Air Flow | Range | Resolution | Area |
| CFM | 0-9999ft³/min | 1 | 0.000-9.999ft2 |
| CMM | 0-9999m³/min | 1 | 0.000-9.999m2 |
| Range of Temperature | |||
| Range | Resolution | Accuracy | |
| °C | -10.0 to 60.0 | 0.1 | ±3.0°C |
| °F | 14.0 to 140.0 | 0.1 | ±6.0°F |
