LUTRON SPM-1116SD SOLAR POWER METER

Click To Zoom

LUTRON SPM-1116SD SOLAR POWER METER

LUTRON SPM-1116SD SOLAR POWER METER

(Based On 10 Reviews)

The SPM-1116SD Solar Power Meter provides accurate and reliable measurements for solar power, power integration, and transmission, making it an essential tool for various environmental and research applications.

Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL Products
100% ORIGINAL Products Details

100% ORIGINAL Products

SECURE Payments
SECURE Payments Details

SECURE Payments

₹ 19,399.00

(GST inclusive price) i
  • Base Value: ₹ 16439.8
  • GST: (18) % ₹ 2959.2
  • Total Value ₹ 19399

₹19,399.00

( - 0% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

Description

Key Features



  • Three Measurement Functions: Measures solar power, power integration, and transmission, offering comprehensive solar power assessment capabilities.
  • Real-Time Data Logging: Saves measurement data along with time information (year, month, date, hour, minute, second) into an SD memory card, enabling easy download to Excel for further data analysis without extra software.
  • Wide Spectral Range: Covers a spectral response range from 400 to 1100 nm, ensuring accurate measurements across various light conditions.
  • Large Backlit LCD Display: Features a large LCD with green backlight for easy readability, displaying multiple measurement parameters simultaneously.
  • Advanced Connectivity: Equipped with RS232/USB computer interface for data output, compatible with optional data acquisition software for enhanced analysis and reporting.
  • Microprocessor Circuit: Ensures high accuracy and reliability with special functions and features.
  • Auto Power Off: Saves battery life with automatic shut off.
  • Data Hold and Memory Recall: Holds and recalls maximum and minimum readings for comprehensive data analysis.
  • Cosine Correction: Ensures accurate readings for angled light up to 60°.
  • Optional Accessories:
  1. SD Card (1 GB, 2 GB)
  2. AC to DC 9V Adapter
  3. USB Cable (USB-01)
  4. RS232 Cable (UPCB-02)
  5. Data Acquisition Software (SW-U801-WIN, SW-E802)





What's in the box?

  • Manual
  • Solar Sensor
  • Hard Carrying Case (CA-06)

Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0
Review Image

Product Specifications

Technical Specifications:



  • Display:
  1. Size: 52 mm x 38 mm large LCD
  2. Backlight: Green



Measurement Functions:



Solar Power:

  • Range: 2000 W/m², 634 Btu/(ft² x h)
  • Resolution:
  1. 0.1 W/m² (<1000 W/m²)
  2. 1 W/m² (≥1000 W/m²)
  3. 0.1 Btu/(ft² x h) (<317 Btu/(ft² x h))
  4. 1 Btu/(ft² x h) (≥317 Btu/(ft² x h))
  • Accuracy: ±10 W/m² or ±3 Btu/(ft² x h), or ±5% reading (whichever is greater in sunlight @ 23 ± 5℃)



Transmission:

  • Range: 0 to 100%
  • Resolution: 0.1%



Power Integration:

  • Units: Wh/m², Btu/(ft²)
  • Resolution: 0.1 Wh/m² or 0.1 Btu/(ft²)



Spectral Response: 400 to 1100 nm



Data Logging:

  1. Interval: 1 second to 3600 seconds (auto)
  2. Manual logging available
  3. SD card capacity: 1 GB to 16 GB



Power Supply:

  1. 6 x 1.5V AA (UM3) batteries
  2. DC 9V adapter (optional)



Power Consumption:

  1. Normal operation (without SD card save and LCD backlight off): Approx. DC 6.5 mA
  2. When SD card saves data but LCD backlight is off: Approx. DC 30 mA
  3. With LCD backlight on: Increases by approx. 16 mA



Operating Environment:

  • Temperature: 0 to 50℃ (32 to 122℉)
  • Humidity: Less than 85% RH



Dimensions and Weight:

  • Main Instrument: 182 x 73 x 47.5 mm (7.1 x 2.9 x 1.9 inches)
  • Sensor Probe: 38 mm DIA x 25 mm
  • Weight: 346 g (0.76 lb)
