MECO PHT 4545 AC Clamp-On Power & Harmonics Tester
Click To Zoom
MECO PHT 4545 AC Clamp-On Power & Harmonics Tester
MECO PHT 4545 AC Clamp-On Power & Harmonics Tester
The Meco PHT4545 is a True RMS AC Clamp-On Power and Harmonics Tester. It measures voltage, current, power, harmonics up to the 99th order, THD, and more, making it ideal for comprehensive power quality analysis
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
1 YEAR WARRANTY
AUTHORIZED DISTRIBUTOR
B2B INVOICES
₹ 56,448
(GST inclusive price) i-
Base Value: ₹ 47837.3
-
GST: (18) % ₹ 8610.7
-
Total Value ₹ 56448
₹74,925.00
( - 25% OFF )
Description
Key Features
- W, KW, HP, VA, KVA, VAR, KVAR
- PF, Phase Angle (Φ)
- Energy (WH, KWH)
- Balanced 3Φ Power Quality
- Balanced 3Φ Sequence
- Programmable CT Ratio (1 to 250)
- Dual Displays (W + PF, VA + KVAR...)
- Active power in HP
- Resistance and Continuity with Beeper
What's in the box?
|
Rating & Reviews
Rating
| General Specification | |
| Jaw Opening | Cable Dia 55mm (approx.), 64 x 24mm (Bus Bar) |
| Power | Two 1.5V AA Battery |
| Display | 4 + 4 Digits LCD |
| Auto-Power-Off | 30 minutes |
| LCD Update Rate | 2 times / sec. |
| Operating Temperature | -10°C to 50°C |
| Storage Temperature | -20°C to 60°C |
| Option | Alligator Clips |
| Power Consumption | 10mA (approx.) |
| No. of Samples / Period | 512 (V & A), 256 (W) |
| Operating Humidity | < 85% Relative |
| Storage Humidity | < 75% Relative |
| Weight | 650gms Including Battery (approx.) |
| Dimension | 271 x 112 x 46mm (approx.) |
| Technical Specification | ||||
| Harmonics of AC Current in % & Magnitude (1~99th order) | ||||
| Range | Resolution in % | Accuracy in % | Resolution in Magnitude | Accuracy in Magnitude |
| 1 ~ 20th | 0.1% | ±2% | 0.1A | ± 2% of reading ± 0.4A |
| 21 ~ 49th | 4% of reading ± 2.0% | ± 4% of reading ± 0.4A | ||
| 50 ~ 99th | 6% of reading ± 2.0% | ± 6% of reading ± 0.4A | ||
| Harmonics of AC Voltage in % & Magnitude (1~99th order) | ||||
| Range | Resolution in % | Accuracy in % | Resolution in Magnitude | Accuracy in Magnitude |
| 1 ~ 20th | 0.1% | ±2% | 0.1A | ± 2% of reading ± 0.4A |
| 21 ~ 49th | 4% of reading ± 2.0% | ± 4% of reading ± 0.4A | ||
| 50 ~ 99th | 6% of reading ± 2.0% | ± 6% of reading ± 0.4A | ||
| Crest Factor(C.F., Accuracy of Readings) | ||
| Range | Resolution | Accuracy |
| 1.00 ~ 99.99 | 0.01 | ± 5% ± 30 dgt |
| AC Current (50 or 60Hz, True RMS) | ||
| Range | Resolution | Accuracy |
| 1.00 ~ 99.99 | 0.1A | ± 2% ± 5 dgts |
| AC Voltage (50 or 60Hz, True RMS) | ||
| Range | Resolution | Accuracy |
| 10.0 ~ 600.0V | 0.1V | ± 0.5% ± 5 dgts |
| Power Factor & Phase Angle | ||
| Range | Resolution | Accuracy |
| 0.000 ~ 1.000 | 0.001 | ± 0.04 |
| -180°to180° & 0°to360° | 0.1° | ± 2° |
| Resistance( ) V and Continuity (Beep if less than 50V) | ||
| Range | Resolution | Accuracy |
| * 7.0 ~ 999.9V | 0.1V | ± 5V |
| 1000 ~ 1200V | 1V | |
