OWON AG 1011F Multi-function waveform generator

Product Specifications

Channel: single
- Frequency Output: 10MHz
- Sample Rate 125MS/s
- Vertical Resolution 14 bits
- Waveform: Standard Sine, Square, Pulse, Ramp, and Noise
- Arbitrary Exponential Rise, Exponential Fall, Sin(x)/x, Step Wave, and others, total 45 built-in waveforms, and user-defined arbitrary waveform
- Frequency (resolution 1μHz): Sine 1μHz - 5MHz 1μHz - 10MHz, Square 1μHz - 5MHz, Pulse 1μHz - 5MHz, Ramp 1μHz - 1MHz
- Noise 5MHz (-3dB) (typical)
- Arbitrary Waveform 1μHz - 5MHz
- Amplitude 1m Vpp - 12.5 Vpp (50Ω), 1m Vpp - 25 Vpp (high impedance)
- Resolution 1mVpp or 14 bits
- ReDC Offset Range (AD+DC) ±6.25V (50Ω), ±12.5V (high impedance)
- DC Offset Range Resolution 1mV
- Load Impedance 50Ω (typical)
- Wave Length 2 pts to 8k pts
- Sample Rate 125MS/s
- Vertical Resolution 14 bits
- Non-volatile Memory 64M byte
- Modulation
- Display 4 inch (480 × 320 pixels) TFT LCD
- Communication Interface USB device
- Dimension (W×H×D) 235 × 110 × 295 (mm)
- Weight (without package) 3.00 kg

Warranty: As per Owon's Policy- 1 Year
