LUTRON SC-941 SOUND CALIBRATOR

LUTRON SC-941 SOUND CALIBRATOR
LUTRON SC-941 SOUND CALIBRATOR

LUTRON SC-941 SOUND CALIBRATOR

Click To Zoom

LUTRON SC-941 SOUND CALIBRATOR

LUTRON SC-941 SOUND CALIBRATOR

(Based On 10 Reviews)

The SC-941 Sound Calibrator provides accurate and reliable calibration for sound level meters, making it an essential tool for various professional applications.

Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL PRODUCTS
Your source for authentic goods. No fakes, just the real deal.

100% ORIGINAL PRODUCTS

SECURE PAYMENTS
Risk-free Transactions

SECURE PAYMENTS

AUTHORIZED DISTRIBUTOR
Get genuine products and full manufacturer support. We are an authorized distributor for Fluke, Meco, Metravi, Mextech, Lutron & SEW.

AUTHORIZED DISTRIBUTOR

B2B INVOICES
Enter your GSTIN at the time of checkout for claiming GST input.

B2B INVOICES

₹ 14,800

(GST inclusive price) i
  • Base Value: ₹ 12542.4
  • GST: (18) % ₹ 2257.6
  • Total Value ₹ 14800

₹17,270.00

( - 14% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

8920884830

Description

Key feature

  • Precise Calibration: Designed to calibrate sound level meters precisely, ensuring accurate measurements in various environments.
  • Standard Frequency and Sound Pressure Level: Features a 1000 Hz frequency and a 94 dB sound pressure level, compliant with IEC942 Class 2 standards for reliable calibration.
  • Compatibility: Suitable for 0.5 inch and 1 inch microphones, providing versatility for different sound level meters.
  • Durable Design: Constructed with a durable bench-type housing case and built-in over input protection for long-lasting use.
  • Battery Operated: Powered by two 9V batteries (006P, MN1604, PP3 or equivalent), with a built-in battery test indicator for convenience.



What's in the box?

  • LUTRON SC-941 SOUND CALIBRATOR
  • Instruction Manual
  • 0.5" Microphone Adapter
  • Adjustment Screw Driver
  • Carrying Case (CA-03)















Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0
Review Image

Product Specifications

Frequency: 1000 Hz ± 2%


Sound Pressure Level: 94 dB ± 0.8 dB


Total Harmonic Distortion: ± 2%


Suitable Microphone Type: 0.5 inch or 1 inch microphone


Standard Compliance: IEC942, Class 2


Operating Temperature: 0 to 50℃ (32 to 122℉)


Power Supply: Heavy duty or Alkaline type, DC 9V battery (006P, MN1604, PP3 or equivalent), 2 PCs


Power Consumption: Approx. DC 7 mA


Battery Check: Built-in battery test indicator


Dimensions: Diameter 50 mm (round) x 145 mm (length)


Weight Approx. 350 g (0.77 lb including batteries)


Calibration Procedures:



1. Microphone Adapter:

   - If using a 0.5" microphone, install the 0.5" mic adapter on the couple section.

   - If using a 1" microphone, remove the 0.5" mic adapter.



2. Insert Microphone: Carefully insert the microphone of the sound level meter into the coupler section of the sound calibrator.



3. Set Sound Level Meter: Adjust the sound level meter to a range suitable for measuring 94 dB.



4. Power On: Set the "Off/BAT. TEST/On Switch" to "ON" position to produce a pure 1000 Hz tone.



5. Adjust Calibration: Adjust the calibration VR (knob) of the sound level meter until the display shows exactly 94.0 dB.
