Metravi DCHV AC High Voltage Test Set upto 30KV
Click To Zoom
Metravi DCHV AC High Voltage Test Set upto 30KV
Metravi DCHV AC High Voltage Test Set upto 30KV
"MERAVI" brand D.C. High Voltage Test Set is suitable for testing electrical insulation of condensers, electric cables, PIV of diodes and many other items like transformers, motors, switch gear products etc. The set is particularly applicable for testing electrical insulation at site where portability is vital.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
1 YEAR WARRANTY
AUTHORIZED DISTRIBUTOR
B2B INVOICES
₹ 4,800
(GST inclusive price) i-
Base Value: ₹ 4067.8
-
GST: (18) % ₹ 732.2
-
Total Value ₹ 4800
₹6,750.00
( - 29% OFF )
Description
Key Features
- Continuously variable autotransformers of suitable capacity.
- Output DC H.V. is measured using a properly designed resistor chain along with an analog micro-ammeter.
- Analog milli ammeter along with press-to-read push button switch for measurement of leakage current.
- Mains 'ON' - 'OFF' Switch & H.T. 'ON' 'OFF' push button switch incorporated. -
- Automatic tripping mechanism for protecting the H.V. transformer against overloading.
- This tripping device is incorporated both on the L.T. side & H.T. side.
- This tripping device senses the leakage current to be higher than the preset value (1mA or 10mA) & trips the entire H.T. Circuit.
- Zero start interlocking will be provided to ensure that the H.V. Circuit cannot be energized unless the voltage regulator is first returned to the Zero position.
- Lamp to indicate L.T. ON.
- Lamp to indicate H.T. ON.
What's in the box?
|
Rating & Reviews
Rating
| General Specification | |
| INPUT | 230 Volts, 50 HZ, Single phase AC. 'OR' 415V 50Hz Three Phase |
| OUTPUT | Continuously variable from zero to 3 KV 'or' 5 KV 'or' 10 KV 'or' 15 KV 'or' 25 KV 'or' 30 KV 'or' 35 KV 'or' 40 KV 'or' 50 KV 'or' 60 KV 'or' 70 KV 'or' 75 KV 'or' 80 KV 'or' 100 KV 'or' 130 KV 'or' 150 KV 'or' 175 KV 'or' 200 KV 'or' 300 KV DC (Any One |
| CAPACITY | Max Permissible transient current is 3/5 mA 'or' 10mA 'or' 20mA 'or' 30mA 'or' 50mA (Any One). |
| DUTY | Intermittent i.e. 5 Mins, 'ON' 10 Mins. 'OFF'. (Test Sets with other duty cycle can also be provided) |
| UNIT | Two 'or' Three units as per the design requirements. |
