Metravi OS-5020C Dual Channel Oscilloscope
Click To Zoom
Metravi OS-5020C Dual Channel Oscilloscope
Metravi OS-5020C Dual Channel Oscilloscope
This is a portable kind of oscilloscope for two traces. The bandwidth is 0~20MHz. Its vertical deflection factor is 5mV/div and to 1mV/div by Magnification. Full bandwidth sweeping circuit is used in the sweeping system. The flexible and convenient triggering mode has the functions for selecting signals from one channel or triggered by Ext signals. And there is another function of ALT trigger to observe signals from two irrelative channels.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
1 YEAR WARRANTY
AUTHORIZED DISTRIBUTOR
B2B INVOICES
₹ 35,200
(GST inclusive price) i-
Base Value: ₹ 29830.5
-
GST: (18) % ₹ 5369.5
-
Total Value ₹ 35200
₹47,250.00
( - 26% OFF )
Description
Key Features
- Dual Trace Dual Channel Oscilloscope with Component Test Facility
- Bandwidth: 20MHz
- A full bandwidth sweeping circuit is used in the sweeping system
- The flexible and convenient triggering mode has the functions for selecting signals from one channel or triggered by Ext signals
- ALT trigger to observe signals from two irrelative channels
- The instrument has the functions of TV-H / TV-V synchronization and trigger-lock to observe all kinds of signals stably
- From the terminal for trigger input, CH1 and CH2 signals can be output along with the triggering channel to connect the Ext frequency counter
- Y deflection operation: Y1, Y2, ALT, CHOP, ADD, mode X-Y
- Vertical Deflection: 5mV/Div to 20V/Div in factor 1-2-5 sequence in 12 steps
- Rising time: < 18nS
- Maximum Input Voltage: 400V (DC +ACp-p)
- Triggering Source: Y1, Y2, ALT, POWER, EXT
- Trigger Coupling: AC/DC (EXT), NORM/TV-H, TV-V
- Horizontal Sweep Mode: AUTO, TRIG, LOCK, SINGLE
- Sweep time factor: 0.1uS/div to 0.2s/div in 1-2-5 sequence in 20 steps
- Magnification: x10
- X-Y Mode input: X-Axis YI and Y-Axis Y2
- Z Axis minimum input level: TTL Level
- Component Test Facility
- Calibration Signal: Square wave of 0.5V at 1kHz
- CTR Display size: 8cm x 10cm
- Auxiliary Power Supply: 230V 50Hz AC
What's in the box?
|
Rating & Reviews
Rating
| Technical Specification | |
| Y Deflection Factor | |
| Operating mode | Y1, Y2, ALT, CHOP, ADD, X-Y |
| Deflection Factor(Y1 or Y2) | 5mV/div~20V/div in 1-2-5 sequence, altogether 12 steps. Error <3% |
| MAG Rate | × 5 Error < 5% |
| Frequency Bandwidth | AC: 10Hz-20MHz-3dB DC: 0-20MHz-3dB |
| Frequency Bandwidth by MAG | AC: 10Hz-5MHz -3dB DC: 0~5MHz -3dB |
| Rising time | <18ns, 70ns by MAG |
| Overshot | ≤5% |
| Damp | ≤5% |
| Coupling Mode | AC DC |
| Input Impedance | 1±5%ΜΩ//≤30pF(direct) 10±5%ΜΩ≤23pF (by probe) |
| Max Safe Voltage | 400V(DC+ACp-p) |
| Slope Inverting | Y2 only |
| Triggering System | |
| Triggering Source | Y1,Y2, ALT, POWER, EXT |
| Coupling | AC/DC(EXT), NORM/TV-H, TV-V |
| Polarity | +,- |
| Synchronized Frequency Range | Auto: 50Hz~20MHz |
| Min. Synchronized | Trig: DC-20MHz |
| Trigger Level | INT: 1div; EXT: 0.2Vp-p Trig Lock (50Hz-10MHz) INT: 2div |
| Input Impedance (by EXT trigger) | 1±5% ΜΩ ≤ //30pF |
| Max Safe Voltage | 400V(DC+ACp-p) |
| X-Y Mode | |
| Signal Input | X-Axis: Y1 Y-Axis: Y2 |
| Deflection Factor | Same as Y1 |
| Frequency Response | AC: 10Hz-1MHz -3dB DC: 0-1MHz -3dB |
| Input Impedance | Same as Y1 |
| Max Safe Voltage | Same as Y1 |
| X-Y Phase Difference | <3°(DC-50kHz) |
| Z-Axis System | |
| Min Input Level | TTL Level |
| Max Input Voltage | 50V(DC+ACp-p) |
| Input Resistance | 10ΚΩ |
| Input Polarity | Low level to brighten |
| Frequency Range | DC∼5MHz |
| Signals for Probe Calibration | |
| Waveform | Square wave |
| Amplitude | 0.5±2% Vp-p |
| Frequency | 1±2%kHz |
| CRT | |
| Persistence | Middle persistence |
| Working Area | 8cm×10cm (1cm=1div) |
| Power Supply | |
| Power | 230 ±10%V |
| Frequency | 50 ± 5%Hz |
| Horizontal System | |
| Sweep mode | AUTO, TRIG, LOCK, SINGLE |
| Sweep time Factor | 0.1µs/div-0.2s/div in 1-2-5 sequence altogether 20 steps Error <3% |
| MAG | ×10 Error <8% |
| Physical Characteristics | |
| Weight | 7.2kg |
| Dimension | 320mm×130mm×400mm |
