Metravi DIT-914 Digital Insulation Tester
Metravi DIT-914 Digital Insulation Tester
(Based On 10 Reviews)
The Metravi DIT-914 Digital Insulation Tester is an auto-ranging device and features low loss, high conversion, inductance tanking, DC Voltage convertor, which converts 9V to 500V/1000V/2500V/5000V. It tests insulation resistance with an analogue/digital circuit.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL Products
SECURE Payments
₹ 16,699.00
(GST inclusive price) i₹22,478.00
( - 26% OFF )
Description
What's in the box?
|
Rating & Reviews
Rating
General Specification | |
Display | 75 X 35 mm Backlit LCD with Annunciator |
Max. Reading | 1999 Counts |
Over the limited range indicator | LCD show "1" |
Power supply | Six AA batteries to supply the power; "OR" 230 V, 50Hz AC |
Power consumption | Static <10mA Max. <300 mA (Median) |
Short circuit current | >2mA (250V~1000V), >1mA (2500V) |
Work condition | Temperature 0 °C ∼ 40 °C , relative humidity: 30%~85% RH |
Storage condition | -10 °C ∼ 40 °C , relative humidity <85%RH |
Dimension | 95 × 148 × 85mm |
Weight | Approx. 850g (including batteries) |
Data Hold | To Freeze the displayed Data |
Technical Specification | ||||
Function | Range | Displaying reading | Accuracy | Remark/Media resistance |
ACV | 750V | 00 | ± (1.2% + 3d) | Frequency response:40~400Hz |
200Ω | 00.0 | ± (0.8% + 3d) | Voltage limit 250V <300beeper alarm | |
ΜΩ500V | 20ΜΩ 200ΜΩ 2000ΜΩ | 0.00 00.0 000 | ± (2% + 5d) ± (2% + 5d) ± (3% + 5d) | 2ΜΩ |
ΜΩ1000V | 20ΜΩ 200ΜΩ 2000ΜΩ | 0.00 00.0 000 | ± (2% + 5d) ± (2% + 5d) ± (3% + 5d) | 10ΜΩ |
ΜΩ2500V | 200ΜΩ 2GΩ 20GΩ | 00.0 000 0.00 | ± (2% + 5d) ± (3% + 5d) ± (5% + 5d) | 20ΜΩ |
ΜΩ5000V | 2GΩ 20GΩ 200GΩ | 000 0.00 00.0 | ± (3% + 5d) ± (5% + 5d) ± (8% + 5d) | 200ΜΩ |
Continuity | Audible Continuity when resistance is less than 302 |
