Metravi PM-05 Multifunction Differential Pressure Manometer

Metravi PM-05 Multifunction Differential Pressure Manometer
Metravi PM-05 Multifunction Differential Pressure Manometer
Metravi PM-05 Multifunction Differential Pressure Manometer
Metravi PM-05 Multifunction Differential Pressure Manometer
Metravi PM-05 Multifunction Differential Pressure Manometer

Click To Zoom

Metravi PM-05 Multifunction Differential Pressure Manometer

Metravi PM-05 Multifunction Differential Pressure Manometer

(Based On 10 Reviews)

The Metravi PM-05 Manometer measures negative, positive and differential pressure. Option for 11 measurement units: bar, ozin², psi, mbar, mmHg, cmH2O, ftH20, kgcm² and kPa.

Request Callback

Order In Bulk

Generate Quote

100% ORIGINAL Products
100% ORIGINAL Products Details

100% ORIGINAL Products

SECURE Payments
SECURE Payments Details

SECURE Payments

₹ 4,764.00

(GST inclusive price) i
  • Base Value: ₹ 4037.3
  • GST: (18) % ₹ 726.7
  • Total Value ₹ 4764

₹6,413.00

( - 26% OFF )

Need Help ?

Our Client Care Managers Are On Call 24/7 To Answer Your Question.

8920884830

Description

Key Features

  • ±30psi / 206.8 kPa Differential Pressure Sensor
  • Built-in option for 11 different measurement units
  • ZERO setting function
  • TPU sheath for protection when using in harsh and rugged environments
  • 32 Data Storage
  • Auto Power-off (manual option available)
  • Accuracy: ±1% FS
  • Linear Hysteresis Phenomenon: ±0.1% FS
  • Max. Pressure Limit: 206.8kPa(*)
  • Repeatability: ±0.25% FS
  • Reaction Time: 0.5 secs (25°C ±2°C)
  • Overload Alert: “HI” display(*)
  • *IMPORTANT NOTE! Excess or over-limit pressure will damage the meter



What's in the box?

  • Metravi PM-05 Multifunction Differential Pressure Manometer
  • Pressure Meter
  •  Hose
  •  Rubber Head
  •  Metal Quick Connector
  •  PP Carry Case
  •  User Manual

Rating & Reviews

4.5
(Based On 10 Reviews)

Rating

0

0

0

0

0
Review Image

Product Specifications

General Specification
Accuracy±1% FS
Linear Hysteresis Phenomenon±0.1% FS
Max. Pressure Limit206.8kPa(*)
Repeatability±0.25% FS
Reaction Time0.5 secs (25°C ±2°C)
Pressure Connection1/8th inch (3.18mm) quick connectors
Operating Temperature0°C~40°C
Storage Temperature-10°C~60°C
Overload Alert"HI" display (*)
Power1 no 9V 6F22 Battery
Weight163 gms
Dimensions155 x 80 x 32 mm



Pressure range table
Pressure unitRangeResolution
Kpa±206.80.1Kpa
bar±2.0680.001bar
ozin²+4800.1 ozin²
psi±300.01 psi
inHg±61.080.01 inHg
mbar+20681 mbar
mmHg±15511 mmHg
cmH2O±21091 cmH2O
ftH2O+69.200.01 ftH2O
inH2O±8300.1 inH2O
Kgcm²±2.1090.001 Kgcm²
