Metravi Pro 474 TRMS AC|DC Digital Clamp Meter
Click To Zoom
Metravi Pro 474 TRMS AC|DC Digital Clamp Meter
Metravi Pro 474 TRMS AC|DC Digital Clamp Meter
The Metravi Pro 474 AC/DC Industrial Clamp Meter features 6000 Counts TFT LCD Color Display, Digital TRMS Multimeter, AC/DC Voltage, AC+DC Voltage, AC/DC Current, Bluetooth interface for PC/Smartphone connection, 100kHz Bandwidth, Trend Capture with zoom in function, Low Pass Filter, MAX / MIN / AVG, PEAK MAX / PEAK MIN, Relative Function and Data Hold Facility, Data Logging, Histogram Data, Real-Time Data Recoding, Auto Power Off, Full Overload Protection, Capacitance, Frequency up to 10MHz, Resistance, Temperature, Duty Cycle.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL Products
SECURE Payments
₹ 24,262.00
(GST inclusive price) i₹32,657.00
( - 26% OFF )
Description
What's in the box?
|
Rating & Reviews
Rating
| General Specification | |
| Clamp Jaw Opening | 1.3” (34mm) approx. |
| Display | 3-5/6 digits (6000counts) TFT Color LCD |
| Continuity Check | Threshold 50W Test current <0.5mA. |
| Diode Test | Test current of 0.3mA typical : Open circuit voltage <3.3V DC typical. |
| Over-Range Indication | “OL” display |
| Measurement Rate | 3 readings per second, nominal |
| Peak | Captures peaks >1ms |
| Temperature Sensor | Type K thermocouple |
| Input Impedance | 10M VDC and 9M VAC |
| AC Response | True RMS (AAC and VAC) |
| Operating Temperature | 5 to 40°C (41 to 104°F) |
| Storage Temperature | -20 to 60°C (-4 to 140°F) |
| Operating Humidity | Max 80% upto 31°C (87°F) decreasing linearly to 50% at 40°C (104°F) |
| Storage Humidity | <80% |
| Operating Altitude | 7000ft. (2000 meters) maximum |
| Battery | Three (3)AAA battery |
| Auto Power Off | After approx. 15-60 minutes. |
| Safety | For indoor use and in accordance with the requirements for double insulation to IEC1010-1 (2001): EN61010-1 (2001) Over voltage Category III 1000V and Category IV 600V, Pollution Degree 2. |
| Technical Specification | |||
| Functions | Range | Resolution | Accuracy |
| DC Voltage | 600.0mV | 0.1mV | ±(0.5% +8 digits) |
| 6.000V | 0.001V | ±(1.5% +5 digits) | |
| 60.00V | 0.01V | ||
| 600.0V | 0.1V | ||
| 1000V | 1V | ||
| AC TRMS Voltage (50Hz-400Hz) | 6.000V | 0.001V | ±(1.5% +5 digits) |
| 60.00V | 0.01V | ||
| 600.0V | 0.1V | ||
| 1000V | 1V | ||
| Low AC TRMS Voltage ( 50Hz-400Hz) | 6.000V | 0.001V | ±(3.0% + 40 digits) |
| 60.00V | 0.01V | ||
| 300.0V | 0.1V | ||
| DC Current | 600.0A | 0.1A | ±(2.5% + 5 digits) |
| 1000A | 1A | ±(2.8% + 5 digits) | |
| AC TRMS Current (50Hz-60Hz) | 600.0A | 0.1A | ±(2.5% + 5 digits) |
| 1000A | 1A | ±(2.8% + 5 digits) | |
| Flexible Coil Current (50Hz-400Hz) | 30.00A | 0.01A | ±(3.0% + 5 digits) |
| 300.0A | 0.1A | ||
| 3000A | 1A | ||
| Resistance and Continuity Test | 600.0Ω | 0.1Ω | ±(1.0% + 10 digits) |
| 6.000kΩ | 0.001kΩ | ±(1.5% + 5 digits) | |
| 60.00kΩ | 0.01kΩ | ||
| 600.0kΩ | 0.1kΩ | ||
| 6.000MΩ | 0.001MΩ | ±(2.5% + 5 digits) | |
| 60.00MΩ | 0.01MΩ | ±(3.5% + 10 digits) | |
| AC+DC TRMS Voltage (50Hz-400Hz) | 6.000V | 0.001V | ±(2.5% + 20 digits) |
| 60.00V | 0.01V | ||
| 600.0V | 0.1V | ||
| 1000V | 1V | ||
| Frequency (Electronic Circuits) | 9.999Hz-99.99kHz | 0.01-10Hz | ±(1.2% + 5 digits) |
| Duty Cycle | 10.0% - 90.0% | 0.1% | ±(1.2% + 8 digits) |
| Capacitance | 60.00nF | 0.01nF | ±(4.0% + 20 digits) |
| 600.0nF | 0.1nF | ±(3.0% + 8 digits) | |
| 6.000µF | 0.001µF | ||
| 60.00µF | 0.01µF | ||
| 600.0µF | 0.1µF | ||
| 6000µF | 1µF | ±(5.0% + 8 digits) | |
| 60.00mF | 0.01mF | ±(5.0% + 20 digits) | |
| 100.0mF | 0.1mF | ||
| Temperature with K-Type Probe | -40.0 to 600.0°C | 0.1°C | ±(1.5% + 3°C) |
| 600 to 1000°C | 1°C | ||
| -40.0 to 600.0°F | 0.1°F | ±(1.5% + 5.4°F) | |
| 600 to 1800°F | 1°F | ||
