Metravi DT-5250W Digital TRMS AC|DC Clamp Meter with Wireless PC Interface
Click To Zoom
Metravi DT-5250W Digital TRMS AC|DC Clamp Meter with Wireless PC Interface
Metravi DT-5250W Digital TRMS AC|DC Clamp Meter with Wireless PC Interface
3-3/4 Digits, Backlit LCD, Peak & Data Hold, T-RMS, Wireless PC Interface, 30mm jaw size, AC/DC Voltage, AC Current, Resistance, Capacitance, Frequency, Temperature, Diode and Continuity Test.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
 bl.png)
1 YEAR WARRANTY
AUTHORIZED DISTRIBUTOR
B2B INVOICES
₹ 10,250.00
(GST inclusive price) i₹13,770.00
( - 26% OFF )
Description
What's in the box?
|
Rating & Reviews
Rating
| General Specification | |
| Clamp Size | 30mm Opening Approx. |
| Diode Test | Test Current of 0.3mA typical |
| Continuity Check | Threshold <352 |
| Low Battery Indication | "" is displayed |
| Overrange Indication | "OL" is displayed |
| Measurement Rate | 2 per second, nominal |
| Input Impedance | 10ΜΩ, (VDC and VAC) |
| Display | 3-3/4 Digits, 4000 count Backlit LCD |
| AC Current | 50/60Hz (AAC) |
| AC Voltage Bandwidth | 50/60Hz (VAC) |
| Operating Temperature | -10°C to 50°C (14°F to 122°F) |
| Storage Temperature | 30° to 60°C (-22°F to 140°F) |
| Relative Humidity | Up to 85% |
| Over Voltage | Category III 600V |
| Battery | One DC 9V IEC6F22 1604 Battery |
| Auto Power Off | Approx. 20 minutes |
| Dimensions | 229 x 80 x 49mm |
| Weight | 303g |
| Technical Specification | |||
| DC Voltage | |||
| Range | Measuring Range | Resolution | Accuracy |
| 40A | 0 to 40.00A | 0.01A | ± (2.8% + 10 digits) |
| 400A | 0 to 400.0A | 0.1A | ± (2.8% + 8 digits) |
| 1000A | 0 to 1000A | 1A | ±(3.0% + 8 digits) |
| AC Current T-RMS | |||
| 40A | 0 to 40.00A | 0.01A | ± (2.8% + 10 digits) |
| 400A | 0 to 400.0A | 0.1A | ± (2.8% + 8 digits |
| 1000A | 0 to 1000A | 1A | ± (3.0% + 8 digits) |
| AC Current T-RMS | |||
| 400mV | 0 to 400.0 mV | 0.1mV | ± (0.8% + 2 digits) |
| 4V | 0 to 4.000V | 0.001V | ± (1.5% + 2 digits) |
| 40V | 0 to 40.00V | 0.01V | |
| 400V | 0 to 400.0V | 0.1V | |
| 600V | 0 to 600V | 1V | ± (2.0% + 2 digits |
| DC Voltage | |||
| 400mV | 0 to 400.0 mV | 0.1mV | ± (1.0% + 10 digits) |
| 4V | 0 to 4.000V | 0.001V | ± (1.5% + 8 digits) |
| 40V | 0 to 40.00V | 0.01V | |
| 400V | 0 to 400.0V | 0.1V | |
| 600V | 0 to 600V | 1V | ± (2.0% + 8 digits |
| Resistance | |||
| 400Ω | 0 to 400Ω | 0.1Ω | ± (1.0% + 4 digits) |
| 4kΩ | 0 to 4.000kΩ | 1Ω | |
| 40kΩ | 0 to 40.00kΩ | 10Ω | ± (1.5% + 2 digits) |
| 400kΩ | 0 to 400.0kΩ | 100Ω | |
| 4MΩ | 0 to 4.00MΩ | 1kΩ | ±(2.5% + 5 digits) |
| 40MΩ | 0 to 40.00MΩ | 10kΩ | ±(3.5% + 10 digits) |
| Capacitance | |||
| 4nF | 0 to 4.000nF | 0.001nF | ± (5.0% + 30 digits) |
| 40nF | 0 to 40.00nF | 0.01nF | ±(5.0% + 20 digits) |
| 400nF | 0 to 400.0nF | 0.1nF | ± (3.0% + 5 digits |
| 4µF | 0 to 4.000μF | 0.001μF | |
| 40μF | 0 to 40.00µF | 0.01μF | |
| 400μF | 0 to 400.0µF | 0.1μF | ±(4.0% + 10 digits) |
| 4mF | 0 to 4.000μF | 0.001mF | ±(4.5% + 10 digits) |
| 40mF | 0 to 40.00mF | 0.01mF | (5.0% + 10 digits) |
| Frequency | |||
| 4kHz | 0 to 4.000kHz | 0.001kHz | ± (1.5% + 2 digits |
| Temperature | |||
| °C | -40°C-1000°C | 1°C | ± (2.5% + 3°C) |
| °F | -40.0°F-1832°F | 1°F | ± (2.5% + 5°F) |
