Metravi PRO 419 Digital TRMS AC|DC Clamp Meter
Click To Zoom
Metravi PRO 419 Digital TRMS AC|DC Clamp Meter
Metravi PRO 419 Digital TRMS AC|DC Clamp Meter
3-3/4 Digits Professional T-RMS AC/DC Clamp Meter, 4000 Counts, 1000V AC T-RMS/DC, 1000A AC T-RMS/DC, Auto Power Off, Non-Contact Voltage Detector, Flashlight, Data Hold, MAX-MIN Record, Relative Measurement, 100mF Capacitance, 100kHz Frequency, 40MΩ Resistance, 1000°C Temperature measurement using K type sensor, Continuity.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
1 YEAR WARRANTY
AUTHORIZED DISTRIBUTOR
B2B INVOICES
₹ 7,550
(GST inclusive price) i-
Base Value: ₹ 6398.3
-
GST: (18) % ₹ 1151.7
-
Total Value ₹ 7550
₹10,800.00
( - 30% OFF )
Description
Key Features
- Professional T-RMS AC/DC Clamp Meter
- 4000 Counts, 3-3/4 Digits Backlit LCD Display
- Confirms to CAT-IV 600V, CAT-III 1000V, CE, IEC-61010-1
- 600V AC/DC Protection in all ranges
- 34 mm Clamp Jaw Dia
- Auto Power Off
- Low Battery Indication
- Non Contact Voltage Detector
- Flash light in the Jaw to access dark Areas
- Double Injection Housing, providing double insulation
- Data Hold, MAX-MIN Record, Relative Measurement
- 1000V AC T-RMS/DC
- 1000A AC T-RMS/DC
- 100mF Capacitance, 100kHz Frequency, 40MOhms Resistance
- Temperature upto1000°C using K type sensor
- Temperature measurement in °C / °F scales
What's in the box?
|
Rating & Reviews
Rating
| General Specification | |
| Clamp Size | Opening 1.4”(35mm) approx. |
| Diode Test | Test current of 0.3mA typical; Open circuit voltage 3.2V DC typical |
| Continuity Check | Threshold ≤50; Test current <0.5mA |
| Over Range Indication | “OL” is displayed |
| Measurements Rate | 2per second, nominal |
| Input Impedance | 10MW (VDC and VAC) |
| Display | 4000 counts LCD |
| AC Current | 50-60Hz (AAC) |
| AC Voltage Bandwidth | 50-400Hz (VAC) |
| Operating Temperature | 50-400Hz (VAC) |
| Storage Temperature | 5 to 40°C (41 to 104°F) |
| Operating Humidity | 20 to 60°C (-4 to 140°F) |
| Storage Humidity | Max 80% up to 31°C (87°F) decreasing linearly to 50% at 40°C (104°F) |
| Operating Altitude | 7000ft. (2000meters) maximum. |
| Over Voltage | Category III 600V |
| Battery | Three ”AAA” 1.5V Batteries |
| Auto OFF | Approx. 30 minutes |
| Safety | For indoor use and in accordance with Over voltage Category II, Pollution Degree2. Category II includes local level, appliance, portable equipment, etc., with transient over voltages less than Over voltage Cat. III |
| Technical Specification | ||
| Function | Range & Resolution | Accuracy (% of reading) |
| AC Current (50/60Hz) | 400.0A AC | ± (2.5% + 8 digits) |
| 1000A AC | ± (2.8% + 8 digits) | |
| DC Current | 400.0A DC | ± (2.5% + 5 digits) |
| 1000A DC | ± (2.8% + 5 digits) | |
| DC Voltage | 400.0mV DC | ± (0.5% + 5 digits) |
| 4.000V DC | ± (1.5% + 2 digits) | |
| 40.00V DC | ||
| 400.0V DC | ||
| 1000V DC | ||
| AC Voltage (50-400Hz) | 4.000V AC | ± (1.5% + 5 digits) |
| 40.00V AC | ||
| 400.0V AC | ||
| 1000V DC | ||
| Resistance | 400.0Ω | ± (1.0% + 4 digits) |
| 4.000kΩ | ± (1.5% + 2 digits) | |
| 40.00kΩ | ||
| 400.0kΩ | ||
| 4.000MΩ | ± (2.5% + 3 digits) | |
| 40.00MΩ | ± (3.5% + 5 digits) | |
| Capacitance | 40.00nF | ± (4.0% reading +20 digits) |
| 400.0nF | ± (3% reading + 5 digits) | |
| 4.000µF | ||
| 40.00µF | ||
| 400.0µF | ||
| 4.000mF | ± (5% reading + 5 digits) | |
| 40.00mF | ± (5% reading + 8 digits) | |
| 100.0mF | + (5% reading + 15 digits) | |
| Frequency Sensitivity: ≥ 5V RMS | 9.999Hz - 99.99kHz | ± (1.2% reading + 5 digits) |
| Duty Cycle Sensitivity: ≥ 5V RMS | 10.0% to 90.0% | ± (1.2% reading + 2 digits) |
| Temp (type-K) (probe accuracy not included) | -20.0 to 1000°C | ± (3% reading + 5°C) |
| -4.0 to1832°F | ± (3% reading + 9°F) | |
