Product Specifications

GENERAL

Enclosure	Double-moulded, Waterproof
Shock (Drop Test)	2 meters (6.5 feet)
Diode Test	Test current of 0.9mA maximum; Open circuit voltage approx 3.2V DC typical.
Continuity Check	Audible signal will sound if the resistance is less than 50W (approx.), test current <0.35mA.
Input Impedance	> 10MW VDC & >10MW VAC
AC Response	True RMS
ACV Bandwidth Crest	45Hz to 1kHz
Factor	≤3 at full scale up to 500V, decreasing linearly to ≤1.5 at 1000V
Display	6000 Counts back-lit liquid crystal
Overrange Indication Auto	"OL" is displayed.
Power Off	15 minutes (approximately) with disabling feature
Polarity	Automatic (no indication for positive); Minus (-) sign for negative
Measurement Rate	3 times per second, nominal
Low Battery Indication	" is displayed if battery voltage drops below operating voltage
Battery	One 9 Volt (NEDA 1604) battery
Fuses	mA/µA ranges: 0.8A/1000V Ceramic Fast Blow; A range: 10A/1000V Ceramic Fast Blow
Operating Temperature	5° to 40°C (41° to 104°F)
Storage Temperature	-20° to 60°C (-4° to 140°F)
Operating Humidity	Max 80% up to 31°C (87°F) decreasing linearly to 50% at 40°C (104°F)
Storage Humidity	<80%
Operating Altitude	2000 meters (7000 ft.) maximum
Safety	This meter is intended for origin of installation use and protected, against the users, by double insulation per EN61010-1 and IEC61010-1, 2nd Edition (2001) to Category IV 600V and Category III 1000V; Pollution Degree 2. The meter also meets UL 61010-1, 2nd Edition (2004), CAN/CSA C22.2 No. 61 010-1, 2nd Edition (2004). and UL 610108-2-031, 1st Edition (2003).

TECHNICAL

Function	Maximum Input
V DC	1500VDC
V AC	1000VAC RMS
mA AC/DC	800mA/1000V fast-acting fuse
A AC/DC	10A/1000V fast acting fuse (30 seconds max every 15 minutes)
Frequency, Duty Cycle, Resistance, CAP, Diode Test, Continuity, Temperature	250VDC/AC RMS
Surge Protection: 8kV peak perIEC 61010

DC Voltage

Range	Resolution	Accuracy
60.00mV	0.01mV	±(0.9% + 9 digits)
600.0mV	0.1mV	±(0.9% + 9 digits)
6.000V	0.001V	±[0.5% + 5 digits]
60.00V	0.01V	±[0.5% + 5 digits]
600.0V	0.1V	±(0.6% + 6 digits)
1500V	lV	±(0.6% + 6 digits)

AC Voltage (45Hzto 1kHz)

Range	Resolution	Accuracy
60.00mV	0.01mV	±(0.9% + 9 digits)
600.0mV	0.1mV	±(0.9% + 9 digits)
6.000V	0.001V	±[0.8% + 3 digits]
60.00V	0.01V	±[0.8% + 3 digits]
600.0V	0.1V	±(0.8% + 8 digits)
1000V	lV	±(0.8% + 8 digits)
All AC Voltageranges are specified from 5% of range to 100% of range. AC Voltage Bandwidth: 45Hz to 1kHz (Sine): 50/60Hz (All wave)

VFD

Range	Resolution	Accuracy
150.0 to 600V	0.1V/1V	1±(4% + 3 digits)

DC Current

Range	Resolution	Accuracy
600.0μA	0.1μA	±(1.0% + 3 digits)
6000μA	1μA
60.00mA	0.01mA
600.0mA	0.1mA
6.000A	0.001A	±(1.5% + 3 digits)
10.00A	0.01A	±(1.5% + 3 digits)
10A: 30 sec max with reduced accuracy.

AC Current (45Hz to 1kHz)

Range	Resolution	Accuracy
600.0μA	0.1μA	±(1.5% + 3 digits)
6000μA	1μA
60.00mA	0.01mA
600.0mA	0.1mA
6.000A	0.001A	±(2.0% + 3 digits)
10.00A	0.01A	±(2.0% + 3 digits)
10A: 30 sec max with reduced accuracy. All AC Currentranges are specifiedfrom 5% of range to 100% of range. AC Current Bandwidth: 45Hz to 1kHz (Sine): 50/60Hz (All wave).

Resistance

Range	Resolution	Accuracy
600.0W	0.1W	±(1.0% +2 diqits)
6.000kW	0.001kW	±(0.8% + 2digits)
60.00kW	0.01kW
600.0kW	0.1kW
6.000MW	0.001MW	±(1.2% +2 digits)
60.00MW	0.01MW	±(1.0% +5 diqits)

Frequency (Electronic)

Range	Resolution	Accuracy
9. 999Hz	0.001Hz	±(0.1% + 4 digits)
99.99Hz	0.01Hz
999.9Hz	0.1Hz
9.999kHz	0.001kHz
99.99kHz	0.01kHz
999.9kHz	0.1kHz
9.999MHz	0.001MHz
Sensitivity : 0.8V RMS min. at 20% to 80% duty cycle and <100kHz; 5V RMS min. at 20% to 80% duty cycle and >100kHz.
