Kusam Meco CA2000 Current Adaptor
Click To Zoom
Kusam Meco CA2000 Current Adaptor
Kusam Meco CA2000 Current Adaptor
The Kusam Meco CA2000 is an AC/DC current clamp adaptor, extending multimeter capabilities to measure up to 2000A. It features a 57mm jaw, 1mV/A output for waveform analysis with oscilloscopes, and an auto-zero function. Its rugged, safety-enhanced design ensures reliable, non-intrusive current measurement.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
1 YEAR WARRANTY
B2B INVOICES
₹ 7,130
(GST inclusive price) i-
Base Value: ₹ 6042.4
-
GST: (18) % ₹ 1087.6
-
Total Value ₹ 7130
₹11,730.00
( - 23% OFF )
Description
Key Features
- Basic Accuracy : 1.5%rdg + 2A
- CA2000 Current Clamp is a transducer which will allow your multimeter to measure electrical Current upto 500/1000/2000 amperes AC or DC, with a Frequency response upto 400Hz.
- The clamp is built with a design of finger guard which ensures user operating the clamp under a safety situation, with a rugged case that is shock resistant and fire-retardant.
- When measuring current with this clamp, there is no need to break a circuit or to affect the isolation.
- It can be used for waveform analysis by connecting it to an oscilloscope. Auto Zero function
What's in the box?
|
Rating & Reviews
Rating
GENERAL
• Jaw Opening Size : 57mm conductor, 70 x 18 mm bus bars
• Measuring Range : 0 to 1500A AC or 0 to 2000A DC max.
• Output : 0 to 1.5V rms or 0 to 2V DC with > 1 Meg Ohms input impedance
• Transfer Rate : 1mV / 1A
• System Accuracy : Current clamp accuracy + DMM accuracy
• Operating Temperature : 0 °C ~ 50 °C; at < 70% R.H.
• Storage Temperature : -20 °C to 60 °C; < 80% R.H.
• Temperature Coefficient : 0.1 x (specified accuracy) / 1 °C (0 °C to 18 °C, 28 °C to 50 °C)
• Altitude : 6561.7 feet (2000M)
• Output : Coil cable with straight banana plug.
• Max. wire length : 3.5 meter when fully stretched.
• Low battery indicator : Red LED lighting.
• Power Supply : 9V DC battery
• Dimension : 100(W) x 224(L) x 40(H) mm
• Weight : Approx. 490 gms. (Including battery)
TECHNICAL
| DC CURRENT | |
| Range | Accuracy |
| 0 ~ 400 A | ± (1.5% rdg + 2 A) |
| 400 A ~ 800 A | ± (2.5% rdg + 2 A) |
| 800 A ~ 1000 A | ± (3.5% rdg + 3 A) |
| 1000 A ~ 2000 A* | ± (3.5% rdg + 3 A) |
| AC CURRENT (Average Sensing) | |
| Range | Accuracy |
| 0 - 400 A / 50 Hz - 60 Hz | ± (1.5% rdg + 2 A) |
| 0 - 400 A / 61 Hz - 400 Hz | ± (3.5% rdg + 2 A) |
| 400 A - 1000 A / 50 Hz - 60 Hz | ± (2.0% rdg + 3 A) |
| 400 A - 1000 A / 61 Hz - 400 Hz | ± (3.5% rdg + 3 A) |
| 1000 A - 1500 A | ± (3.5% rdg + 3 A |
