Metravi PRO ETS+ Smart Electrical Tester
Click To Zoom
Metravi PRO ETS+ Smart Electrical Tester
Metravi PRO ETS+ Smart Electrical Tester
The Swiss army knife for electricians. Only tester measuring DC Current via Fork Jaw. 4 digit backlit display. Fork Opening 16mm. Up to 1500V with LED light alarm & readings. 0-200A AC/DC Current measurement. Single Pole Phase Test. Phase Rotation Test. Resistance, Frequency, Continuity & Diode test, Cable Break test using NCV, Duty Cycle, Self Test. Flashlight, Auto Power-off, Test Leads with storage clips. CAT IV 600V, CAT III 1000V, IP64 protection.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
1 YEAR WARRANTY
AUTHORIZED DISTRIBUTOR
B2B INVOICES
₹ 9,440
(GST inclusive price) i-
Base Value: ₹ 8000
-
GST: (18) % ₹ 1440
-
Total Value ₹ 9440
₹13,500.00
( - 30% OFF )
Description
Key Features
- Designed to meet international safety standards, EN61243-3:2014
- Measurement category CATIV 600V and CATIII 1000V
- T-RMS Measurements
- Voltage test up to 1000V AC and DC with LEDs
- Current test up to 200A AC/DC (PRO ETS+) and 200A AC (PRO ETS)
- Voltage test up to 1000V AC and up to 1500V DC with LCD
- Open Jaw Size 16mm
- Impact and shock proof due the robust design with IP64 protection
- Cable break test using Non-contact Voltage detection (NCV)
- Polarity indication
- Single-pole Phase test
- Phase Rotation test
- Continuity & Diode tests
- Resistance measurement
- Frequency measurement
- Vibration motor
- Auto-power ON / OFF
- Built-in Flashlight
What's in the box?
|
Rating & Reviews
Rating
| Display | 4 digit 7 segment Backlit LCD |
| LED Display Indication | For Voltage, Polarity indication, Single pole, Continuity and Rotary Field |
| Voltage Indication | Buzzer & Vibration if Voltage is higher than 50V AC or 120V DC |
| Voltage Range | 0 - 1000V AC TRMS (15-800Hz); 0 -1500V DC (±) |
| LED Nominal Voltage | 120/230/400/690/1000V |
| LED Tolerance | EN 61243-3 |
| ELV Indication | >50V AC; < 120V DC |
| LED Response Time | <1s at 100% for each nominal value |
| LCD Range | 0 〜 1000V AC (15-800Hz), 0 〜 1500V DC (±0.1V) |
| LCD Resolution | 0.1V (1- 29.9V), 1V (30 〜 1500V) |
| LCD Accuracy | ±3% ±1.5 V (1 〜 29.9V), ±3% ±3dgt (30 〜 1500V) |
| LCD Over-range Indication | "OL" |
| Current Test | 0.1 〜 200A AC (PRO ETS), 0.1 〜 200A AC/DC (PRO ETS+); Accuracy (+/-3%+5dgt), Resolution 0.1A, Frequency 45 〜 65 Hz (Only for double insulated cables) |
| Zero Function | Keep tester away from any current carrying conductors, press both buttons until LCD shows “Zero” and wait until the buzzer sounds 3 times |
| Safety Current | Is <3.5mA at 1000V AC; <6mA at 1500V DC |
| Measurement Duty | 30s ON, 240 s OFF |
| Internal Battery Consumption | Approx. 120mA |
| Single-Pole Phase Test Voltage Range | 100 〜 1000V AC (50/60 Hz) |
| Phase Rotation Test Continuity Test | 170 〜 1000V phase-to-phase AC (40 - 70Hz) |
| Resistance Measurement | 0 100 kΩ; Accuracy: ±5% ±10dgt @25°C 〜 Resolution: 1Ω (1〜2000Ω), 1kΩ (2〜100 kΩ) |
| Frequency Measurement | 1 〜 800Hz ±5% ±5dgt; Resolution: 1Hz |
| Continuity Test | 0 〜 500 kΩ + 50% |
| Diode Test | Yes |
| NCV (Non-contact Voltage detection) Test | 100 〜 1000V AC (50/60 Hz) |
| Data Hold | Yes |
| Low Battery Indication | Yes, on LCD display |
| Battery | 3V (IEC LR03 1.5 V x 2) |
| Environment Temperature | -15° 〜 55°C Operation; -20° 〜 70°C Storage |
| Environment Humidity | No condensation, Max. 85%RH |
| Altitude | Up to 2000m |
| Standards | CATIV 600V, CATIII 1000V, EN/IEC 61243-3:2014 |
| Protection | IP64 Dust & Splash Proof |
| Dimensions | (L x W x D) 210 x 60 x 40 mm |
| Weight | Approx 270 g (with test leads attached) |
