SEW 8025 LP Loop Impedance | PSC Tester
SEW 8025 LP Loop Impedance | PSC Tester
(Based On 10 Reviews)
The SEW 8025 LP is a digital loop and PSC tester used to measure loop impedance and perform wiring checks. It features a 15mA loop measurement that won't trip ELCBs and is easy to use for direct measurements without bypassing wires.
Request Callback
Order In Bulk
Generate Quote
₹ 14,042.00
(GST inclusive price) i₹14,042.00
( - 0% OFF )
Description
What's in the Box
|
Rating & Reviews
Rating
SPECIFICATIONS
Loop Impedance | |||
Range | Measuring range | Nominal test current at 0 Ω external loop | Accuracy |
20 Ω | 0.00~19.99 Ω | 23A / 40ms | (2%rdg + 4dgt) |
200 Ω | 0.0~199.9 Ω | 2.3A / 40ms | |
2000 Ω | 0~1999 Ω | 15mA / 400ms |
Prospective Short-circuit Current | |||
Range | Measuring range | Nominal test current at 0 Ω external loop | Accuracy |
20 KA | 0.00~4.00 KA | 23A / 40ms | Consider accuracy of loop impedance |
2000 A | 0~1999 A | 23A / 40ms | |
200 A | 0.0~199.9 A | 2.3A / 40ms |
Voltage Display | ||
Measuring range | Accuracy | Remark |
150~260 V | (2%rdg + 4dgt) | at 0 Ω external loop |
General | |
Temperature | 0 ~ 40 °C |
System voltage | 230V (+13%) ( -15%) |
System frequency | 50Hz |
None Battery system voltage | 150V ~ 260V |
Over Temperature Protection | When overheating,the " " symbol will show on the LCD, and the 8025LP stop measuring |
Wiring check | P-E LEDs illuminate when the wiring polarity of circuit undertest is correct |
P-N LEDs illuminate when the wiring polarity of circuit undertest is correct | |
N-E LED is light when P and N are reversed or the Earth is not connected | |
15mA Loop measurement | Loop impedance 2000Ω range measurement is carried out with low test current (15mA). The current will not cause tripping out for ELCBs. |
