Mitutoyo Digimatic Indicator
.webp "Mitutoyo Digimatic Indicator")
Click To Zoom
Mitutoyo Digimatic Indicator
Mitutoyo Digimatic Indicator
The Mitutoyo ABSOLUTE Digimatic Indicator (ID Series) is a reliable, easy-to-use digital indicator featuring an ABSOLUTE sensor for no repeated origin setting, large 9mm display for clear readability, long battery life, and user-friendly functions like zero set, origin set, inch/mm conversion, and data output for precise and efficient measurements.
What's in the box?
|
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
1 YEAR WARRANTY
B2B INVOICES
₹ 9,443
(GST inclusive price) i-
Base Value: ₹ 8002.5
-
GST: (18) % ₹ 1440.5
-
Total Value ₹ 9443
₹17,461.00
( - 46% OFF )
Description
Key Features
| Range | 12.7mm |
| Digital step | 0.01mm |
| Max. Permissible Error E MPE | 0.02mm |
| H MPE (Hysteresis) | 0.02mm |
| R MPE (Repeatability) | 0.01mm |
| Type | EN ISO Standard |
| Measuring Force | <1,5N |
| Protection | IP42 |
| Mass | 150g |
| Display | LCD, character height 9mm |
| Max. response speed | Unlimited |
| Alarm | Low voltage, counting value composition error |
| Stem ⌀ | 8mm |
| Contact point | carbide ball, thread M 2.5 x 0.45mm |
| Battery life | approx. 18000 hours (0.001 mm type), |
| approx. 20000 hours (0.01 mm type) | |
| Power supply | 1 battery SR-44 |
| Data output | yes |
| ON/OFF | yes |
| Origin (ABS-Zero) | yes |
| Counting direction switchable | yes |
| Digital/Analog | Digital |
| Inch-Metric | Metric |
| Delivered | Including 1 battery |
Rating & Reviews
Rating
Product Specifications
| TITLE | MODEL | RANGE | LEAST COUNT | ACCURACY |
| Digimatic Indicator | 543-781 | 0-12.7mm | 0.01mm | 0.02mm |
| Order No. | Resolution | Range | Measuring force | |
| W/ lug back | W/ flat back | |||
| 543-781 | 543-781B | 0.01mm | 12.7mm | 1.5N or less |
| TECHNICAL DATA | |
| Accuracy: | Refer to the list of specifications |
| Resolution: | 0.01mm |
| Display: | LCD |
| Length standard: | ABSOLUTE electrostatic capacitance type linear encoder |
| Max. response speed: | Unlimited |
| Measuring force: | Refer to the list of specifications |
| Battery: | SR44 (1 pc.), 938882 |
| Battery life: | Approx. 20,000 hours under normal use |
| Dust/Water protection level: | IP42 (IP53: 543-794B, 543-795B, 543-796B) |
