Rishabh RISH i-Young Digital Multi Meter
Click To Zoom
Rishabh RISH i-Young Digital Multi Meter
Rishabh RISH i-Young Digital Multi Meter
RISHABH iYoung is suited for universal, general applications in the electrical and electronics fields, as well as in radio and television service, training and education. It is of especially pocket size design, and thus fit into pocket. The protective cover, which is provided as standard equipment, can be opened at an angle for convenient reading from the workbench, and provides for easy transport.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
₹ 1,660
(GST inclusive price) i-
Base Value: ₹ 1406.8
-
GST: (18) % ₹ 253.2
-
Total Value ₹ 1660
₹2,846.00
( - 42% OFF )
Description
Key Features
- Direct and alternating voltages from 100µV ... 600V
- Direct and alternating currents from 10µA ... 10.00A
- Resistance from 1Ω... 40.00M with zero correction
- Frequencies from 10.00Hz ... 500kHz
- Diode measurement and continuity testing
- Data Hold.
- Relative measurement
- Duty cycle (%) measurement
- Non Contact Voltage Detection
What's in the box?
|
Rating & Reviews
Rating
GENERAL
- Display: 7 segment
- Character height: Main Display Character : 12.9 mm
- Number of digits/Counts: digits 3999 steps 3 ¾3
- Overrange display: “OL” is displayed.
- Polarity display: “–” sign is displayed when positive pole at “ ”
- Sampling rate: 3 measurements/s for V, I , , Capacitance, Frequency and Duty cycle measurement
- Protection Instruments: IP 52
- Connector sockets: IP 20
- Dimensions W x H x D:
- With Holster: 74.3 mm x 154.1 mm x 47.6 mm
- Without Holster : 68.3 mm x 142.9 mm x 39.3 mm
- Weight Approx. 0.350 Kg with battery
TECHNICAL
| Reference Temperature | 23°C ± 2K |
| Relative Humidity | 45%...55% RH |
| Waveform of measured quantity | Sinusoidal |
| Input frequency | 50 Hz |
| Battery Voltage | 3 V ± 0.1 V |
| EMC Immunity | IEC 61326-1:2012, Table A.1 * |
| Immunity | IEC 61000-4-2 : 8 KV atmosphere discharge, 4 KV contact discharge |
| IEC | 61000-4-3 : 3 V/m |
| Safety | IEC 61010-1-2010 |
| IP for water & dust | IEC 60529 |
| Pollution degree | 2 |
| High Voltage Test | 3.6 kV |
| Operating temperature | 0 to +50°C |
| Storage temperature | - 25 to +70°C (without battery) |
| Relative humidity | 45%.......75% |
| Terminal Protection | IP 52 for instrument and IP20 for terminals. . |
| Altitude | Up to 2000 m |
| Battery Voltage | 2 X 1.5 V Cells |
| Battery type | Alkaline manganese Dioxide cells. |
| Battery Life | Alkaline manganese dry cell: approx. 400 hours. |
| Battery test | Automatic display of symbol when battery voltage drops below 2.4 0.1V + |
| Influence Quantity | Range of Influence | Measured Quantity /Measuring Range | Variation ± (….%of rdg. + ….digits) |
| Temperature | 0 ºC + 21 ºC and +25 °C to 50 °C | V, A, Diode, F, Hz, %, OHM | 1.5 × intrinsic error / 10K |
| Relative humidity | 75% 3 Days Meter off | 1 × intrinsic error | |
| Frequency of Measured Quantity | 20 Hz.....<50 Hz | 400mV~, 600V~ | 3.5 + 3 |
| >50 Hz ....500 Hz | |||
| 20 Hz.....<50 Hz | 4V~, 40V~, 400V~ | ||
| >50 Hz ....750 Hz | |||
| Battery Variation | Upto Low Battery | V, A, Diode, Hz, %, OHM | 20D |
| F | 70D |
| Measurement Function | Measuring Range | Resolution | Input Impedance | Intrinsic Uncertainty under Reference Condition ±(…% of the rdg.+…Digits) | Overload Capacity | |||
| DC | AC/ACDC | DC | AC | Value Time | Value Time | |||
| V | 400.0 mV | 100 µV | >10 M | 1 + 9 | 2 +9 | |||
| 4.000 V | 1 mV | 1 + 9 | 1.5 + 9 | 1050 V | Continu ous | |||
| 40.00 V | 10 mV | 1 + 9 | 1.5 + 9 | |||||
| 40.00 V | 100 mV | 1 + 9 | 1.5 + 9 | |||||
| 600 V | 1 V | 1 + 9 | 1.5 + 9 | |||||
| Voltage Drop. Approx | 480 mA | Continu ous | ||||||
| mA | 40.00 mA | 10 µA | 45 mV | 1.5 + 9 | 1.5 + 9 | |||
| 400.0 mA | 100 µA | 450 mV | 1.5 + 9 | 1.5 + 9 | ||||
| A | 4.000 A | 1 mA | 45 mV | 2 + 5 | 2.5 + 9 | 12 A: = 30 s | ||
| 10.00 A | 10 mA | 120 mV | 2 + 5 | 2.5 + 9 | ||||
| Input | Input Impedance | |||||||
| Ω | 400 | 100 mΩ | approx. 0.45V | 1 + 5 | 500V DC/AC rms | 5 min | ||
| 4.000 kΩ | 1Ω | 1 + 5 | ||||||
| 40.00 kΩ | 10Ω | 1 + 5 | ||||||
| 400.0 kΩ | 100Ω | 1.5 + 5 | ||||||
| 4.000 MΩ | 1 kΩ | 2 + 5 | ||||||
| 40 MΩ | 10 kΩ | 2.5 +5 | ||||||
| Continuity | 400.0Ω | 100 mΩ | 1.5 + 5 | |||||
| Diode | 1.0V | 1 mV | approx. 1V | 2.5 + 5 | ||||
| F | 5.000 nF | 1 pF | 5 + 40 | |||||
| 50.00 nF | 10 pF | 3 + 10 | ||||||
| 500.0 nF | 100 pF | 1.5 + 10 | ||||||
| 5.000 µF | 1 nF | 2 + 10 | ||||||
| 50.00 µF | 10 nF | 2 + 10 | ||||||
| 200.0 µF | 100 nF | 5 + 40 | ||||||
| Hz | 9.999 Hz | 0.001Hz | 9 Hz | 0.5 + 5 | 500V DC/AC rms | 5 min | ||
| 99.99 Hz | 0.01Hz | 9 Hz | ||||||
| 999.9 Hz | 0.1Hz | 9 Hz | ||||||
| 9.999 kHz | 1Hz | 9 Hz | ||||||
| 99.99 kHz | 10Hz | 9 Hz | ||||||
| 500.0 kHz | 100Hz | 9 Hz | ||||||
| Duty Cycle | 2....98% | 0.10% | 10Hz.....1kHz 5D 1kHz...10kHz 5D/kH | |||||
