KYORITSU 2003A Digital Clamp Meter
Click To Zoom
KYORITSU 2003A Digital Clamp Meter
KYORITSU 2003A Digital Clamp Meter
The KEW 2003A is a digital clamp meter designed to measure both AC and DC current, voltage, resistance, and continuity. It features large transformer jaws for measuring currents up to 2000A on conductors up to Ø55mm.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
₹ 25,449
(GST inclusive price) i-
Base Value: ₹ 21566.9
-
GST: (18) % ₹ 3882.1
-
Total Value ₹ 25449
₹37,045.00
( - 31% OFF )
Description
Key Features
- Measurement of both AC and DC current with transformer jaws of large diameter
- Can measure AC and DC currents up to 2000A
- Output terminal for recorder connection
- AC/DC voltage, resistance measurement and continuity functions also available
- Minimum resolution 0.1A
What's in the box?
|
Rating & Reviews
Rating
| AC A | 400/2000A (0 - 1000A) 2000A (1001 - 1999A) |
| DC A | 400/2000A ±1.5%rdg±2dgt |
| AC V | 400/750V ±1.5%rdg±2dgt [50/60Hz] ±1.5%rdg±4dgt [40Hz - 1kHz] |
| DC V | 400/1000V ±1%rdg±2dgt |
| Ω | 400/4000Ω ±1.5%rdg±2dgt |
| Continuity buzzer | Buzzer sounds below 50±35Ω |
| Conductor size | Ø55mm max. |
| Frequency response | 40Hz - 1kHz |
| Output | Recorder : DC400mV against AC/DC400A DC200mV against AC/DC2000A |
| Safety standard | IEC 61010-1 CAT IV 600V / CAT III 1000V IEC 61010-031 , IEC 61010-2-032 |
| Power source | R6 (AA) (1.5V) × 2 |
| Dimension | 250(L) × 105(W) × 49(D)mm |
| Weight | Approx. 530g |
