KYORITSU 1021R DIGITAL MULTIMETER
KYORITSU 1021R DIGITAL MULTIMETER
(Based On 10 Reviews)
The KEW 1021R is a digital multimeter designed for electricians and electronics engineers. It is a compact and versatile instrument for measuring AC | DC voltage, resistance, and continuity
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL Products
SECURE Payments
₹ 7,600.00
(GST inclusive price) i₹13,207.00
( - 42% OFF )
Description
What's in the box
|
Rating & Reviews
Rating
Product Specifications
DC V | 6.000/60.00/600.0V (Auto-ranging) ±0.5%rdg ±3dgt |
DC mV | 600.0mV ±1.5%rdg ±3dgt |
DC Clamp Sensor | 60.00/200.0A (Auto-ranging) ±1.5%rdg ±3dgt + Sensor accuracy |
AC V | 6.000/60.00/600.0V (Auto-ranging) ±1.0%rdg ±3dgt [40 - 500Hz] |
AC mV | 600.0mV ±2.0%rdg ±3dgt [40 - 500Hz] |
AC Clamp Sensor | 60.00/200.0A (Auto-ranging) ±2.0%rdg ±3dgt + Sensor accuracy [40 - 500Hz] |
DC A | 6.000/10.00A (Auto-ranging) ±1.5%rdg ±3dgt |
AC A | 6.000/10.00A (Auto-ranging) ±1.5%rdg ±3dgt[45 - 500Hz] |
Ω | 600.0Ω/6.000/60.00/600.0kΩ/6.000/40.00MΩ (Auto-ranging) ±0.5%rdg ±4dgt (600Ω) ±0.5%rdg ±2dgt (6/60/600kΩ/6MΩ) ±1.5%rdg ±3dgt (40MΩ) |
Continuity buzzer | 600Ω (Buzzer sounds below 90Ω) |
Diode test | Open circuit voltage: < 3.0V |
Capacitance | 60.00/600.0nF/6.000/60.00/600.0/1000µF ±2.0%rdg ±5dgt (60/600nF) ±5.0%rdg ±5dgt (6/60/600/1000µF) |
Frequency | ACV 99.99/999.9Hz/9.999/99.99kHz ±0.1%rdg ±3dgt ACA 99.99/999.9Hz/9.999kHz ±0.1%rdg ±3dgt |
DUTY | 10.0 - 90.0% ±1.0%rdg ±3dgt [50/60Hz] |
Applicable standards | IEC 61010-1 CAT IV 300V / CAT III 600V / CAT II 1000V IEC 61010-2-033, IEC 61010-031, IEC 61326-2-2 (EMC), EN 50581 (RoHS) |
Power source | R03 (1.5V) × 2 |
Dimension | 155(L) × 75(W) × 40(D)mm |
Weight | Approx. 250g (including batteries) |
