Fluke 9040 Phase Rotation Indicator
Fluke 9040 Phase Rotation Indicator
The Fluke 9040 is effective for measuring phase rotation in all areas where three phase supplies are used to feed motors, drives and electrical systems. The Fluke 9040 is a rotary field indicator and can provide clear indication of the 3 phase via an LCD display and the phase rotation direction to determine correct connections. It allows rapid determination of phase sequence and has a voltage (up to 700 V) and frequency range suitable for commercial and industrial applications. The included test probes have a variable clamping range for safe contact, also in industrial sockets.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
2.png)
2 YEARS WARRANTY
AUTHORIZED DISTRIBUTOR
B2B INVOICES
₹ 55,399
(GST inclusive price) i-
Base Value: ₹ 46948.3
-
GST: (18) % ₹ 8450.7
-
Total Value ₹ 55399
₹73,656.00
( - 25% OFF )
Description
Key Features
- 3 phase indication
- Indication of phase rotation
- Clear LCD display
- No battery required
Phase rotation indicator with high voltage capability for industrial applications
The Fluke 9040 is effective for measuring phase rotation in all areas where three phase supplies are used to feed motors, drives and electrical systems. The Fluke 9040 is a rotary field indicator and can provide clear indication of the 3 phase via an LCD display and the phase rotation direction to determine correct connections. It allows rapid determination of phase sequence and has a voltage (up to 700 V) and frequency range suitable for commercial and industrial applications. The included test probes have a variable clamping range for safe contact, also in industrial sockets.
What's in the box?
|
Rating & Reviews
Rating
| Technical Specifications | |
| Voltage Range | 40-700 V |
| Frequency Range | 15-400 Hz |
| Operating Timer | Continuous |
| Environmental Specifications | |
| Operating Temperature | 0°C to 40°C |
| Dust/Water Resistance | IP 40 |
| Safety Specifications | |
| Electrical Safety | EN 61010, |
| EN 61557-7 | |
| Overvoltage category | CAT III, 600 V |
| CAT IV, 300V | |
| Mechanical and General Specifications | |
| Size | 124 x 61 x 27 mm |
| Weight | 200 g |
| Power supply | From unit under test |
| Warranty | 2 years |
