Megger MIT1025 Insulation Resistance Tester
Megger MIT1025 Insulation Resistance Tester
The MIT1025 is a high-performance 10 kV insulation tester capable of IR, PI, DAR, DD, SV, and Ramp Tests with resistance up to 20 TΩ. It features onboard memory, USB connectivity, RTC time/date stamping, and advanced test modes. Built for industrial environments, it includes a dual protective case, IP65 rating, rapid-charge battery, and CAT IV 600 V safety rating.
Request Callback
Order In Bulk
Generate Quote
100% ORIGINAL PRODUCTS
SECURE PAYMENTS
₹ 5,29,000
(GST inclusive price) i-
Base Value: ₹ 448305.1
-
GST: (18) % ₹ 80694.9
-
Total Value ₹ 529000
₹6,34,800.00
( - 17% OFF )
Description
Key Features:
- Max Insulation Resistance: Up to 20 TΩ @ 10 kV
- Capacitance Measurement: Available (for voltages >5000 V)
- Test Modes:
- IR
- Timed IR
- PI (Polarisation Index)
- DAR (Dielectric Absorption Ratio)
- DD (Dielectric Discharge)
- SV (Stepped Voltage)
- Ramp Test
- Short Circuit Current: 3 mA
- High Noise Rejection: 3 mA @ 10 kV
- Memory & Communication:
- Advanced onboard memory with on-screen recall
- Real-time clock for date/time stamping of test results
- USB interface for data download
- Software Compatibility:
- PowerDB Lite (for PC-based test result management)
- CertSuite Asset: Cloud-based result syncing to Android or Windows devices via USB
- Test Result Enhancement:
- Ability to save ambient temperature (from external instruments) with results
- Safety & Construction:
- Dual-case design for durability (shock- and fire-resistant)
- IP65 rated (case closed) for dust/moisture protection
What's in the box?
|
Rating & Reviews
Rating
| Test Voltage Ranges | 500 V, 1000 V, 2500 V, 5000 V, 10000 V |
| User-Defined Voltage Range | 100 V–1 kV (10 V steps), 1 kV–10 kV (25 V steps) |
| Test Modes | IR, IR(t), DAR, PI, SV, DD, Ramp |
| Display | Large backlit LCD (analogue + digital) |
| Voltmeter Range | 30 V to 660 V AC/DC, 45–65 Hz |
| Voltmeter Accuracy | ±3%, ±3 V |
| Capacitance Measurement | 10 nF to 25 µF (above 500 V) |
| Capacitance Accuracy | ±10% ±5 nF |
| Memory / Data Logging | ✅ Onboard memory with recall |
| PC Connectivity / USB | ✅ USB interface available |
| Software Support | ✅ PowerDB Lite & CertSuite compatible |
| Battery Life | ~4.5 hours (typical) @ 10 kV, 100 MΩ load |
| Charging Time | 2 hrs (normal), 2.5 hrs (deep discharge) |
| AC Power Input | 90–264 V rms, 47–63 Hz, 100 VA |
| IP Rating | IP65 (lid closed), IP40 (lid open) |
| Operating Temp. Range | -20 °C to +50 °C |
| Storage Temp. Range | -25 °C to +65 °C |
| Humidity Rating | 90% RH non-condensing @ 40 °C |
| Max Altitude | 3000 m |
| Safety Rating | CAT IV 600 V |
| Dimensions (L × W × H) | 315 mm × 285 mm × 181 mm |
| Weight (approx.) | ~4.5 kg (with battery) |
| Technical Specifications | |
| Resistance Range (Digital) | 10 kΩ to 20 TΩ |
| Display Range (Analogue) | 100 kΩ to 10 TΩ |
| Accuracy (±5%) | Up to 2 TΩ @ 10 kV |
| Accuracy (±20%) | Up to 20 TΩ @ 10 kV |
| Current Range | 0.01 nA to 6 mA |
| Current Accuracy | ±5% ±0.2 nA @ all voltages (20 °C) |
| Short Circuit Current | 3 mA |
| Noise Rejection | 3 mA from 960 V to 10 kV |
| Guard Terminal Performance | Guards down to 500 kΩ, max 1% error @ 100 MΩ |
| Capacitor Charge Time | <5 s/µF at 3 mA to 10 kV |
| Capacitor Discharge Time | <250 ms/µF from 10 kV to 50 V |
| Insulation Test Alarm Range | 100 kΩ to 10 GΩ |
| Timer Range | Up to 99 min 59 sec (min 15 sec setting) |
| Battery Type | 10.8 V, 5.2 Ah Li-ion (IEC 62133:2003) |
| Capacitance Measurement Trigger | Only active above 500 V test voltage |
